18 Transfer protocol

Sensor KNX VOC/TH-UP Touch • Version: 30.11.2021 • Technical changes and errors excepted.

106 VOC threshold value 1: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

107 VOC threshold value 1: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

108 VOC threshold value 1: Switching

output

Output R-CT [1.1] DPT_Switch 1 Bit

109 VOC threshold value 1: Switch out-

put block

Input -WC- [1.2] DPT_Bool 1 Bit

110 VOC threshold value 2: Absolute

value

Input /

Output

RWC

[9.8] DPT_Value_Air-

Quality

2 Bytes

111 VOC threshold value 2: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit

112 VOC threshold value 2: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

113 VOC threshold value 2: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

114 VOC threshold value 2: Switching

output

Output R-CT [1.1] DPT_Switch 1 Bit

115 VOC threshold value 2: Switch out-

put block

Input -WC- [1.2] DPT_Bool 1 Bit

116 VOC threshold value 3: Absolute

value

Input /

Output

RWC

[9.8] DPT_Value_Air-

Quality

2 Bytes

117 VOC threshold value 3: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit

118 VOC threshold value 3: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

119 VOC threshold value 3: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

120 VOC threshold value 3: Switching

output

Output R-CT [1.1] DPT_Switch 1 Bit

121 VOC threshold value 3: Switch out-

put block

Input -WC- [1.2] DPT_Bool 1 Bit

122 VOC threshold value 4: Absolute

value

Input /

Output

RWC

[9.8] DPT_Value_Air-

Quality

2 Bytes

123 VOC threshold value 4: (1:+ | 0:-) Input -WC- [1.2] DPT_Bool 1 Bit

124 VOC threshold value 4: Switching

delay from 0 to 1

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

125 VOC threshold value 4: Switching

delay from 1 to 0

Input -WC- [7.5] DPT_TimePeri-

odSec

2 Bytes

126 VOC threshold value 4: Switching

output

Output R-CT [1.1] DPT_Switch 1 Bit

127 VOC threshold value 4: Switch out-

put block

Input -WC- [1.2] DPT_Bool 1 Bit

128 VOC controller: Block object Input -WC- [1.2] DPT_Bool 1 Bit

129 VOC controller: Setpoint Input /

Output

RWC

[9.8] DPT_Value_Air-

Quality

2 Bytes

No Text Function Flags DPT type Size
