54 Adjustment
Room Controller KNX Touch One Style • Status: 30.07.2020 • Errors excepted. Subject to technical changes.
5.1. Start menu
5.1.1. Set the Start Menu (ETS)
There are six free display positions in the Start Menu that can be occupied with func-
tions The six functions are arranged as follows:
Function 1 Function 4
Function 2 Function 5
Function 3 Function 6
By default the TH sensor's temperature and humidity value are displayed as functions
1 and 4 (external proportions are included).
5.1.1.1. List of internal functions
No function
TH sensor temperature
TH sensor humidity
Light 1 (2, 3, 4, 5, 6, 7, 8)
Blind 1(2, 3, 4, 5, 6)
Awning 1 (2, 3, 4)
Shutter 1 (2, 3, 4
Window 1 (2)
Ventilation unit
5.1.1.2. List of object functions
For object function „Display ...“ the received value/text is shown on the display only.
For object function „Input ...“ a value/text can be edited on the display and sent with
OK.
No function
Display 1 / 0
Display Up (for value 0) / Down (for value 1)
Display Up (for value 1) / Down (for value 0)
Transfer the name of the object function
(Note: The names of the internal functions
are always transferred. If you activate this
by clicking Yes, the names of the object
functions are also transferred to the
display)
No • Yes
Functions 1, 2, 3, 4, 5, 6 linked with • Internal function
• Object function
Function • No function
• All activated internal functions
• All activated object functions
Name Text input field
