24 Description
Room Controller KNX Touch One Style • Status: 30.07.2020 • Errors excepted. Subject to technical changes.
423
Button 3 dimming
Input /
Output
RWCT [3.7] DPT_Con-
trol_Dimming
4 bit
424
Button 3 - 8-bit encoder
Output R-CT [5] 5.xxx 1 Byte
425
Button 3 - 16-bit encoder
Output R-CT [9] 9.xxx 2 bytes
426
Button 3 Scene
Output R-CT [5] 5.xxx 1 Byte
427
Button 4 Extended
Output R-CT [1.8] DPT_Up-
Down
1 bit
428
Button 4 Brief
Output R-CT [1.10] DPT_Start 1 bit
429
Button 4 switching
Input /
Output
RWCT [1.1] DPT_Switch 1 bit
430
Button 4 dimming
Input /
Output
RWCT [3.7] DPT_Con-
trol_Dimming
4 bit
431
Button 4 - 8-bit encoder
Output R-CT [5] 5.xxx 1 Byte
432
Button 4 - 16-bit encoder
Output R-CT [9] 9.xxx 2 bytes
433
Button 4 Scene
Output R-CT [5] 5.xxx 1 Byte
440
Actuating variable compara-
tor 1: Input 1
Input -WC- [5.1] DPT_Scaling 1 Byte
441
Actuating variable compara-
tor 1: Input 2
Input -WC- [5.1] DPT_Scaling 1 Byte
442
Actuating variable compara-
tor 1: Input 3
Input -WC- [5.1] DPT_Scaling 1 Byte
443
Actuating variable compara-
tor 1: Input 4
Input -WC- [5.1] DPT_Scaling 1 Byte
444
Actuating variable compara-
tor 1: Input 5
Input -WC- [5.1] DPT_Scaling 1 Byte
445
Actuating variable compara-
tor 1: Output
Output R-CT [5.1] DPT_Scaling 1 Byte
446
Actuating variable compara-
tor 1: Block
Input -WC- [1.2] DPT_Bool 1 bit
447
Actuating variable compara-
tor 2: Input 1
Input -WC- [5.1] DPT_Scaling 1 Byte
448
Actuating variable compara-
tor 2: Input 2
Input -WC- [5.1] DPT_Scaling 1 Byte
449
Actuating variable compara-
tor 2: Input 3
Input -WC- [5.1] DPT_Scaling 1 Byte
450
Actuating variable compara-
tor 2: Input 4
Input -WC- [5.1] DPT_Scaling 1 Byte
451
Actuating variable compara-
tor 2: Input 5
Input -WC- [5.1] DPT_Scaling 1 Byte
452
Actuating variable compara-
tor 2: Output
Output R-CT [5.1] DPT_Scaling 1 Byte
N0. Text Function Flags DPT Typ Size
