46 Parameter setting
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
Humidity control status humidification
Humidity control status humidification inverted
Switching output coolant temperature
Switching output coolant temperature inverted
Switching output cooling medium temperature
Switching output cooling medium temperature inv.
Switching output room climate status
Switching output room climate status inverted
6.13.3. Connection inputs of the OR logic
The OR logic connection inputs correspond to those of the AND logic. In addition the
following inputs are available for the OR logic:
AND logic 1
AND logic output 1 inverted
AND logic output 2
AND logic output 2 inverted
AND logic output 3
AND logic output 3 inverted
AND logic output 4
AND logic output 4 inverted
6.14. Display
Adjust the display settings here.
Set contrast and number of lines, as well as the type of temperature target value display.
Use display lighting No • Yes
Brightness in % up to 1. Communication 0 ... 255; 100
Lighting always on • only when operating
Switch off delay after operation until 1st
communication (in seconds)
1 ... 600; 10
Saving brightness and switch off delay • never
• after power restoration
• after power restoration and
programming
Use object "display contrast" No • Yes
Display mode • two lines
(with optional thermostat display)
• three lines
(with optional thermostat display)
• Permanent thermostat
Temperature controller display when using
pushbutton
No • Yes
only possible if the pushbuttons are also set to "For temperature control")
