33 Parameter setting
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
The minimum and maximum readings can be saved and sent to the bus. Use the
„Reset humidity min/max value“ object to reset the values to the current readings. The
values are not retained after a reset.
6.7. Humidity threshold values
Activate the required air humidity threshold values. The menus for setting the thresh-
old values are displayed.
6.7.1. Threshold value 1, 2
Threshold value
Set, in which cases threshold values and delay times received via objects are to be
retained. The parameter is only taken into consideration if the setting via object is ac-
tivated below. Please note that the setting "After power supply restoration and pro-
gramming" should not be used for the initial start-up, as the factory settings are always
used until the first communication (setting via objects is ignored).
Set the threshold value directly in the application program using parameters, or define
them via the bus using a communication object.
Threshold value setting using parameter:
Set the threshold values and hysteresis directly.
Threshold value setting using a communication object:
Define, how the threshold value is to be received from the bus. Basically, a new value
can be received, or simply a command to increase or decrease.
During initial commissioning, a threshold value must be defined, which will be valid
until the first communication with a new threshold value. For units which have already
been taken into service, the last communicated threshold value can be used. Basically,
a humidity range is specified in which the threshold value can be changed (object value
limit).
At and above change of
(if sent on change)
0.1% RH • 0.2% RH • 0.5% RH • 1.0% RH • ...
• 25% RH
Send cycle
(if sent periodically)
5 s • 10 s • ... • 2 h
Use minimum and maximum value No • Yes
Use threshold value 1/2 Yes • No
Threshold value setting using Parameter • Communication objects
Threshold value in 0.1% RH
(valid until 1st communication)
0 … 100; 70
