15 Transfer protocol
Sensor KNX TH-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
136 Comparator 1 actuating variable:
Input 2
Input -WC- [5.1]
DPT_Scaling
1 Byte
137 Comparator 1 actuating variable:
Input 3
Input -WC- [5.1]
DPT_Scaling
1 Byte
138 Comparator 1 actuating variable:
Input 4
Input -WC- [5.1]
DPT_Scaling
1 Byte
139 Comparator 1 actuating variable:
Input 5
Input -WC- [5.1]
DPT_Scaling
1 Byte
140 Comparator 1 actuating variable:
Output
Output R-CT [5.1]
DPT_Scaling
1 Byte
141 Comparator 1 actuating variable:
Block
Input -WC- [1.2]
DPT_Bool
1 Bit
142 Comparator 2 actuating variable:
Input 1
Input -WC- [5.1]
DPT_Scaling
1 Byte
143 Comparator 2 actuating variable:
Input 2
Input -WC- [5.1]
DPT_Scaling
1 Byte
144 Comparator 2 actuating variable:
Input 3
Input -WC- [5.1]
DPT_Scaling
1 Byte
145 Comparator 2 actuating variable:
Input 4
Input -WC- [5.1]
DPT_Scaling
1 Byte
146 Comparator 2 actuating variable:
Input 5
Input -WC- [5.1]
DPT_Scaling
1 Byte
147 Comparator 2 actuating variable:
Output
Output R-CT [5.1]
DPT_Scaling
1 Byte
148 Comparator 2 actuating variable:
Block
Input -WC- [1.2]
DPT_Bool
1 Bit
149 AND logic 1: 1-bit switching output Output R-CT [1.1]
DPT_Switch
1 Bit
150 AND logic 1: 8-bit output A Output R-CT [5]
5.xxx
1 Byte
151 AND logic 1: 8-bit output B Output R-CT [5]
5.xxx
1 Byte
152 AND logic 1: Block Input -WC- [1.2]
DPT_Bool
1 Bit
153 AND logic 2: 1-bit switching output Output R-CT [1.1]
DPT_Switch
1 Bit
154 AND logic 2: 8-bit output A Output R-CT [5]
5.xxx
1 Byte
155 AND logic 2: 8-bit output B Output R-CT [5]
5.xxx
1 Byte
156 AND logic 2: Block Input -WC- [1.2]
DPT_Bool
1 Bit
157 AND logic 3: 1-bit switching output Output R-CT [1.1]
DPT_Switch
1 Bit
No Name Function Flags Data Point Type Size
