Elsner KNX T-UP Touch handleiding
Handleiding
Je bekijkt pagina 3 van 46
1 Content
Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany
Sensor KNX T-UP Touch from ETS programme version 1.0
Status: 05.09.2022 • Technical changes and errors excepted.
1. Safety and operating instructions ....................................................... 5
2. Description ........................................................................................... 5
3. Commissioning .................................................................................... 6
3.1. Addressing the equipment ...................................................................................... 6
4. Display and operation at the device .................................................... 6
4.1. Mode display and manual temperature controller ................................................ 7
4.2. Change ambient temperature with the buttons .................................................... 8
5. Transfer protocol ............................................................................... 10
5.1. List of all communications objects ....................................................................... 10
6. Parameter setting .............................................................................. 17
6.1. Behaviour on power failure/ restoration of power .............................................. 17
6.2. General settings ..................................................................................................... 17
6.3. Temperature value ................................................................................................. 18
6.4. Temperature threshold values .............................................................................. 18
6.4.1. Threshold value 1, 2, 3 ............................................................................... 18
6.4.1.1. Threshold value ............................................................................ 18
6.4.1.2. Switching output .......................................................................... 19
6.4.1.3. Block .............................................................................................. 20
6.5. Temperature PI control .......................................................................................... 21
6.5.0.1. General control ............................................................................. 21
6.5.0.2. General set point values .............................................................. 23
6.5.0.3. Set point Comfort ......................................................................... 23
6.5.0.4. Standby setpoint ........................................................................... 24
6.5.0.5. Eco setpoint ................................................................................... 24
6.5.0.6. Setpoint values for frost/heat protection (building protection) 25
6.5.0.7. General control variables ............................................................. 25
6.5.1. Heating control level 1/2 ............................................................................. 26
6.5.2. Cooling control level 1/2 ............................................................................. 28
6.6. Variable comparator .............................................................................................. 30
6.6.1. Control variable comparator 1/2 ................................................................ 30
6.7. Logic ........................................................................................................................ 31
6.7.0.1. AND logic ....................................................................................... 31
6.7.0.2. OR logic ......................................................................................... 31
6.7.1. AND logic 1-4 and OR logic outputs 1-4 ................................................... 31
6.7.1.1. Block .............................................................................................. 33
6.7.2. Connection inputs of the AND logic .......................................................... 33
6.7.3. Connection inputs of the OR logic ............................................................. 34
6.8. Display ..................................................................................................................... 35
6.9. Pushbutton .............................................................................................................. 36
6.9.1. Pushbutton for temperature control ......................................................... 37
6.9.2. Pushbutton interface .................................................................................. 37
