17 Parameter setting
Sensor KNX T-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
6. Parameter setting
6.1. Behaviour on power failure/ restoration of
power
Behaviour following a failure of the bus power supply:
The device sends nothing.
Behaviour on bus restoration of power and following programming or reset:
The device sends all outputs according to their send behaviour set in the parameters
with the delays established in the "General settings" parameter block.
6.2. General settings
Set the basic data transfer characteristics and select whether or not malfunction ob-
jects should be sent.
249 Push button 2 switching Output R-CT [1.1]
DPT_Switch
1 Bit
250 Push button 2 dimming Input /
Output
RWCT [3.7]
DPT_Control_Dim-
ming
4 Bit
251 Push button 2 encoder 8 bit Output R-CT [5]
5.xxx
1 Byte
252 Push button 2 encoder 16 bit Output R-CT [9]
9.xxx
2 Bytes
253 Push button 2 scene Output R-CT [5]
5.xxx
1 Byte
Send delay after power-up and programming for:
Measured values 5 s • ... • 2 h
Threshold values and switching outputs 5 s • ... • 2 h
Controller objects 5 s • 10 s • ... • 2 h
Logic outputs 5 s • 10 s • ... • 2 h
Maximum telegram quota • 1 message per second
• ...
• 5 messages per second
• ...
• 20 messages per second
Use temperature malfunction object Yes • No
No Name Function Flags Data Point Type Size
