14 Transfer protocol
Sensor KNX T-UP Touch • Version: 05.09.2022 • Technical changes and errors excepted.
155 AND logic 2: 8 bit output B Output R-CT [5]
5.xxx
1 Byte
156 AND logic 2: Switching output
block
Input -WC- [1.2]
DPT_Bool
1 Bit
157 AND logic 3: 1 bit switching out-
put
Output R-CT [1.1]
DPT_Switch
1 Bit
158 AND logic 3: 8 bit output A Output R-CT [5]
5.xxx
1 Byte
159 AND logic 3: 8 bit output B Output R-CT [5]
5.xxx
1 Byte
160 AND logic 3: Switching output
block
Input -WC- [1.2]
DPT_Bool
1 Bit
161 AND logic 4: 1 bit switching out-
put
Output R-CT [1.1]
DPT_Switch
1 Bit
162 AND logic 4: 8 bit output A Output R-CT [5]
5.xxx
1 Byte
163 AND logic 4: 8 bit output B Output R-CT [5]
5.xxx
1 Byte
164 AND logic 4: Switching output
block
Input -WC- [1.2]
DPT_Bool
1 Bit
181 OR logic 1: 1 bit switching out-
put
Output R-CT [1.1]
DPT_Switch
1 Bit
182 OR logic 1: 8 bit output A Output R-CT [5]
5.xxx
1 Byte
183 OR logic 1: 8 bit output B Output R-CT [5] 5.xxx 1 Byte
184 OR logic 1: Switching output
block
Input -WC- [1.2]
DPT_Bool
1 Bit
185 OR logic 2: 1 bit switching out-
put
Output R-CT [1.1]
DPT_Switch
1 Bit
186 OR logic 2: 8 bit output A Output R-CT [5]
5.xxx
1 Byte
187 OR logic 2: 8 bit output B Output R-CT [5]
5.xxx
1 Byte
188 OR logic 2: Switching output
block
Input -WC- [1.2]
DPT_Bool
1 Bit
189 OR logic 3: 1 bit switching out-
put
Output R-CT [1.1]
DPT_Switch
1 Bit
190 OR logic 3: 8 bit output A Output R-CT [5]
5.xxx
1 Byte
191 OR logic 3: 8 bit output B Output R-CT [5]
5.xxx
1 Byte
192 OR logic 3: Switching output
block
Input -WC- [1.2]
DPT_Bool
1 Bit
No Name Function Flags Data Point Type Size
