50 Parameter setting
Sensor KNX AQS/TH-UP Touch • Version: 02.08.2022 • Technical changes and errors excepted.
6.16. Logic
The device has 16 logic inputs, four AND- and four OR-logic gates.
Activate the logic inputs and assign object values up to 1st communication. Then, ac-
tivate the required logic outputs.
Activate the required logic outputs.
AND logic
OR logic
Output sends • on change of output
• on change of output and periodically
• when receiving an input object
• when receiving an input object and peri-
odically
From change of
(is only sent if "on change" is selected)
1% • 2% • 5% • 10% • 20% • 25%
Send cycle
(is only sent if "periodically" is selected)
5 s • 10 s • 30 s • ... • 5 min • … • 2 h
Analysis of the blocking object • at value 1: block | at value 0: release
• at value 0: block | at value 1: release
Blocking object value
before 1st communication
0 • 1
Behaviour of the switching output
With blocking • do not send message
• Send value
Sent value in % 0 ... 100
Use logic inputs Yes • No
Object value before 1st communication for
- Logic input 1 0 • 1
- Logic input ... 0 • 1
- Logic input 16 0 • 1
AND logic 1 not active • active
AND logic ... not active • active
AND logic 4 not active • active
OR logic 1 not active • active
OR logic ... not active • active
OR logic 4 not active • active
