Je bekijkt pagina 22 van 66
20 Transfer protocol
Sensor KNX AQS/TH-UP Touch • Version: 02.08.2022 • Technical changes and errors excepted.
239 Display_Return approval Input -WC- [1.1]
DPT_Switch
1 Bit
240 Pushbutton 1 long-term Output R-CT [1.8]
DPT_UpDown
1 Bit
241 Pushbutton 1 short-term Output R-CT [1.10]
DPT_Start
1 Bit
242 Pushbutton 1 switching Input/
Output
R-CT [1.1]
DPT_Switch
1 Bit
243 Pushbutton 1 Relative dimming Input/
Output
RWC
T
[3.7]
DPT_Control_Dim-
ming
4 Bit
244 Pushbutton 1 encoder 8 bit Output R-CT [5]
5.xxx
1 Byte
245 Pushbutton 1 encoder 16 bit Output R-CT [9]
9.xxx
2 Bytes
246 Pushbutton 1 Scenario Output R-CT [5]
5.xxx
1 Byte
247 Pushbutton 2 long-term Output R-CT [1.8]
DPT_UpDown
1 Bit
248 Pushbutton 2 short-term Output R-CT [1.10]
DPT_Start
1 Bit
249 Pushbutton 2 switching Input/
Output
R-CT [1.1]
DPT_Switch
1 Bit
250 Pushbutton 2 Relative dimming Input/
Output
RWC
T
[3.7]
DPT_Control_Dim-
ming
4 Bit
251 Pushbutton 2 encoder 8 bit Output R-CT [5]
5.xxx
1 Byte
252 Pushbutton 2 encoder 16 bit Output R-CT [9]
9.xxx
2 Bytes
253 Pushbutton 2 Scenario Output R-CT [5]
5.xxx
1 Byte
221 Display lighting (1 = on | 0 = off) Input -WC- [1.1]
DPT_Switch
1 Bit
222 Display lighting brightness Input RWC
T
[5.1]
DPT_Scaling
1 Byte
223 Display lighting switch-off delay Input RWC
T
[7.5]
DPT_TimePeriodSec
2 Bytes
No Name Function Flags Data Point Type Size
