16 Transfer protocol
Sensor KNX AQS/TH-UP Touch • Version: 02.08.2022 • Technical changes and errors excepted.
120 CO2 threshold value 3: Switching
output
Output R-CT [1.1]
DPT_Switch
1 Bit
121 CO2 threshold value 3: Switching
output block
Input -WC- [1.2]
DPT_Bool
1 Bit
122 CO2 threshold value 4: Absolute
value
Input/
Output
RWC
T
[9.8]
DPT_Value_AirQua-
lity
2 Bytes
123 CO2 threshold value 4: (1:+ | 0:-) Input -WC- [1.2]
DPT_Bool
1 Bit
124 CO2 threshold value 4: Switching
delay from 0 to 1
Input -WC- [7.5]
DPT_TimePeriodSec
2 Bytes
125 CO2 threshold value 4: Switching
delay from 1 to 0
Input -WC- [7.5]
DPT_TimePeriodSec
2 Bytes
126 CO2 threshold value 4: Switching
output
Output R-CT [1.1]
DPT_Switch
1 Bit
127 CO2 threshold value 4: Switching
output block
Input -WC- [1.2]
DPT_Bool
1 Bit
128 CO2 controller: Blocking object Input -WC- [1.2]
DPT_Bool
1 Bit
129 CO2 controller: Target value Input/
Output
RWC
T
[9.8]
DPT_Value_AirQua-
lity
2 Bytes
130 CO2 controller: Target value (1:+ |
0:-)
Input -WC- [1.2]
DPT_Bool
1 Bit
131 CO2 controller: Control variable
ventilation (stage 1)
Output R-CT [5.1]
DPT_Scaling
1 Byte
132 CO2 controller: Control variable
ventilation (stage 2)
Output R-CT [5.1]
DPT_Scaling
1 Byte
133 CO2 controller: Ventilation 1 status
(1=ON | 0=OFF)
Output R-CT [1.1]
DPT_Switch
1 Bit
134 CO2 controller: Ventilation 2 status
(1=ON | 0=OFF)
Output R-CT [1.1]
DPT_Switch
1 Bit
135 Comparator 1 actuating variable:
Input 1
Input -WC- [5.1]
DPT_Scaling
1 Byte
136 Comparator 1 actuating variable:
Input 2
Input -WC- [5.1]
DPT_Scaling
1 Byte
137 Comparator 1 actuating variable:
Input 3
Input -WC- [5.1]
DPT_Scaling
1 Byte
138 Comparator 1 actuating variable:
Input 4
Input -WC- [5.1]
DPT_Scaling
1 Byte
139 Comparator 1 actuating variable:
Input 5
Input -WC- [5.1]
DPT_Scaling
1 Byte
140 Comparator 1 actuating variable:
Output
Output R-CT [5.1]
DPT_Scaling
1 Byte
No Name Function Flags Data Point Type Size
