83 Set up display screens
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
16-bit floating point
32-bit counter without math. symbol
32-bit counter with math. symbol
32-bit floating point
Select a name for this function. A name can be selected for each of the six available
languages (max. 15 characters).
Editable text language, Page 40
Select the rotary control function. Then select a symbol.
Symbol overview, Page 91
Further settings depend on the function.
Temperature function
RGB control function
8-bit value function (0 ... 255 / 0...100% / 0...360°)
Name
Languages 1...6 [free text]
Function
see above Rotary control functions:
Rotary control symbol • no symbol
• symbol 1
...254 (internal library, see
table Symbol overview, Page 91)
• image selection (from SD card, see
Exchanging images and graphics, Page 18
Text for unit
°C
Minimum value in 0.1°C
-32768 ... 32767
Maximum value in 0.1°C
-32768 ... 32767
Resolution in 0.1°C
(observe settings range)
1 ... 10000; 10
Start value in 0.1°C
-32768 ... 32767; 0
RGB ratios set via • one object (1 x 3 byte)
• three objects (3 x 1 byte)
Text for unit
[free text]
%
°
Minimum value
0 ... 255 (in 0.1°C)
0
... 100
0
... 360
Maximum value
0 ... 255 (in 0,1°C)
0 ... 100
0 ... 360
