40 System settings via ETS
Display Corlo Touch KNX • Status: 30.08.2021 • Technical changes and errors reserved.
2.3. Editable text language
Individually entered text can be saved in several languages. The displayed language
can be changed via an object, on the display or in the ETS menu.
ETS: Select editable text language
Object control
In case of language selection via an object, i.e. the bus, use the object table from the
chapter "System language". The object no. 4 "Editable text language selection" is input
and output simultaneously, and thus may both receive a switching command or
transmit the status to the bus autonomously.
The language object may be activated in the ETS.
Adaptation on the display
The language settings on the display is done via the menu
Settings > system > editable text language
and can be secured with an access code (set up in the ETS).
System settings via touch display > Editable text language, Page 56
Modification via ETS
Select "Transmit the following parameters: Yes" to render the modifications valid.
Previous settings are then overwritten - including modifications done on the display!
The language menu on the display can be secured with an access code that is
determined (or deleted) in the ETS.
Use object for language • No
(no language change via object)
• Yes
(language change via object activated)
Transfer the following parameters Yes • No
Access code
(8 digits from 0 to 9)
[free text]
An empty field means that no code query is
done
Language
when using the language object:
(valid till 1st communication)
• Languages 1...-6
