82 Temperature parameter settings
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
7. Temperature parameter settings
In the following all parameters are described that are found in devices with a temper-
ature sensor, i.e. in Cala KNX T, Cala KNX TH and Cala KNX AQS/TH.
7.1. Temperature Measurement
Select, whether a malfunction object is to be sent if the sensor is faulty.
When measuring temperature, the self-heating of the device is considered by the
electronics. The heating is compensated for in the device.
Use Offsets to adjust the readings to be sent.
Measurement variations from permanent sources of interference can be corrected in
this way.
The unit can calculate a mixed value from its own reading and an external value. Set
the mixed value calculation if desired. If an external portion is used, all of the following
settings (threshold values, etc.) are related to the overall reading.
The minimum and maximum readings can be saved and sent to the bus. Use the
"Reset temperature min/max. value" objects to reset the values to the current readings.
The values are not retained after a reset.
7.2. Temperature threshold values
Activate the required temperature threshold values. The menus for setting the thresh-
old values are displayed.
Use malfunction object No • Yes
Offset in 0.1°C -50…50; 0
Use external measured value No • Yes
Ext. Reading proportion of the total reading 5% • 10% • ... • 50% • ... • 100%
Sending pattern for internal and total
measured value
• never
• periodically
• on change
• on change and periodically
At and above change of
(if sent on change)
0.1°C • 0.2°C • 0.5°C • ... • 5.0°C
Send cycle
(if sent periodically)
5 s • 10 s • ... • 2 h
Use minimum and maximum value No • Yes
Use threshold value 1/2/3/4 Yes • No
