51 Transfer protocol
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
593 OR logic 6: 1-bit switching output Output R-CT [1.2] DPT_Bool 1 bit
594 OR logic 6: 8-bit output A Output R-CT [5.010] DPT_Val-
ue_1_Ucount
1 byte
595 OR logic 6: 8-bit output B Output R-CT [5.010] DPT_Val-
ue_1_Ucount
1 byte
596 OR logic 6: Block Input -WC- [1.1] DPT_Switch 1 bit
597 OR logic 7: 1-bit switching output Output R-CT [1.2] DPT_Bool 1 bit
598 OR logic 7: 8-bit output A Output R-CT [5.010] DPT_Val-
ue_1_Ucount
1 byte
599 OR logic 7: 8-bit output B Output R-CT [5.010] DPT_Val-
ue_1_Ucount
1 byte
600 OR logic 7: Block Input -WC- [1.1] DPT_Switch 1 bit
601 OR logic 8: 1-bit switching output Output R-CT [1.2] DPT_Bool 1 bit
602 OR logic 8: 8-bit output A Output R-CT [5.010] DPT_Val-
ue_1_Ucount
1 byte
603 OR logic 8: 8-bit output B Output R-CT [5.010] DPT_Val-
ue_1_Ucount
1 byte
604 OR logic 8: Block Input -WC- [1.1] DPT_Switch 1 bit
Inputs (objects 621-664)
for all models
621 Push-button 1 long-term Output R-CT [1.8] DPT_Up-
Down
1 bit
622 Push-button 1 short-term Output R-CT [1.10] DPT_Start 1 bit
623 Push-button 1 switching Output R-CT [1.1] DPT_Switch 1 bit
624 Push button 1 dimming Input/
Output
RWCT [3.7] DPT_Con-
trol_Dimming
4 bit
625 Push-button 1 encoder 8 bit Output R-CT [5.10] DPT_Val-
ue_1_Ucount
1 byte
626 Push-button 1 encoder 16 bit Output R-CT [9] 9.xxx 2 bytes
627 Button 1 Scene (call up) Output R-CT [18,001]
DPT_SceneCon-
trol
1 byte
628 Button 1 NTC measured value Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
629 Button 1 NTC external measured
value
Input -WC- [9.1] DPT_Val-
ue_Temp
2 bytes
630 Button 1 NTC total measured value Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
631 Button 1 NTC malfunction Output R-CT [1.1] DPT_Switch 1 bit
632 Push-button 2 long-term Output R-CT [1.8] DPT_Up-
Down
1 bit
633 Push-button 2 short-term Output R-CT [1.10] DPT_Start 1 bit
634 Push-button 2 switching Output R-CT [1.1] DPT_Switch 1 bit
No. Text Function Flags DPT type Size
