46 Transfer protocol
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
426 Comparator 4 actuating variable:
Input 5
Input -WC- [5.1] DPT_Scaling 1 byte
427 Comparator 4 actuating variable:
Output
Output R-CT [5.1] DPT_Scaling 1 byte
428 Comparator 4 actuating variable:
Block (1: block)
Output -WC- [1.2] DPT_Bool 1 bit
Computer (multi-function modules) (objects 441-504)
for all models
441 Computer 1: Input I1 Input RWCT Depending on
setting
4 bytes
442 Computer 1: Input I2 Input RWCT Depending on
setting
4 bytes
443 Computer 1: Input I3 Input RWCT Depending on
setting
4 bytes
444 Computer 1: Output O1 Output R-CT Depending on
setting
4 bytes
445 Computer 1: Output O2 Output R-CT Depending on
setting
4 bytes
446 Computer 1: Condition text Output R-CT [16.0]
DPT_String_ASCII
14 bytes
447 Computer 1: Monitoring status Output R-CT [1.1] DPT_Switch 1 bit
448 Computer 1: Block (1: block) Input -WC- [1.1] DPT_Switch 1 bit
449 Computer 2: Input I1 Input RWCT Depending on
setting
4 bytes
450 Computer 2: Input I2 Input RWCT Depending on
setting
4 bytes
451 Computer 2: Input I3 Input RWCT Depending on
setting
4 bytes
452 Computer 2: Output O1 Output R-CT Depending on
setting
4 bytes
453 Computer 2: Output O2 Output R-CT Depending on
setting
4 bytes
454 Computer 2: Condition text Output R-CT [16.0]
DPT_String_ASCII
14 bytes
455 Computer 2: Monitoring status Output R-CT [1.1] DPT_Switch 1 bit
416 Computer 2: Block (1: block) Input -WC- [1.1] DPT_Switch 1 bit
457 Computer 3: Input I1 Input RWCT Depending on
setting
4 bytes
458 Computer 3: Input I2 Input RWCT Depending on
setting
4 bytes
459 Computer 3: Input I3 Input RWCT Depending on
setting
4 bytes
460 Computer 3: Output O1 Output R-CT Depending on
setting
4 bytes
