44 Transfer protocol
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
351 CO2 threshold value 3: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
352 CO2 threshold value 3: Delay from 0
to 1
Input -WC- [7.005] DPT_-
TimePeriodSec
2 bytes
353 CO2 threshold value 3: Delay from 1
to 0
Input -WC- [7.005] DPT_-
TimePeriodSec
2 bytes
354 CO2 threshold value 3: Switching
output
Output R-CT [1.1] DPT_Switch 1 bit
355 CO2 threshold value 3: Switching
output block
Input -WC- [1.1] DPT_Switch 1 bit
356 CO2 threshold value 4: Absolute
value
Input/
Output
RWCT [9,008] DPT_Val-
ue_AirQuality
2 bytes
357 CO2 threshold value 4: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
358 CO2 threshold value 4: Delay from 0
to 1
Input -WC- [7.005] DPT_-
TimePeriodSec
2 bytes
359 CO2 threshold value 4: Delay from 1
to 0
Input -WC- [7.005] DPT_-
TimePeriodSec
2 bytes
360 CO2 threshold value 4: Switching
output
Output R-CT [1.1] DPT_Switch 1 bit
361 CO2 threshold value 4: Switching
output block
Input -WC- [1.1] DPT_Switch 1 bit
CO2 controller (objects 362-368)
for Cala KNX AQS/TH (item no. 70613, 70614)
362 CO2 controller: Block (1: block) Input -WC- [1.2] DPT_Bool 1 bit
363 CO2 controller: Target value Input/
Output
RWCT [9,008] DPT_Val-
ue_AirQuality
2 bytes
364 CO2 controller: Target value
(1:+ | 0:-)
Input -WC- [1.2] DPT_Bool 1 bit
365 CO2 controller: Act. variable
ventilation
Output R-CT [5.1] DPT_Scaling 1 byte
366 CO2 controller: Act. variable
ventilation level 2
Output R-CT [5.1] DPT_Scaling 1 byte
367 CO2 controller: Ventilation status
(1:ON | 0:OFF)
Output R-CT [1.1] DPT_Switch 1 bit
368 CO2 controller: Status ventilation
level 2 (1=ON | 0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
Act. variable comparator (objects 401-428)
for all models
401 Comparator 1 actuating variable:
Input 1
Input -WC- [5.1] DPT_Scaling 1 byte
402 Comparator 1 actuating variable:
Input 2
Input -WC- [5.1] DPT_Scaling 1 byte
403 Comparator 1 actuating variable:
Input 3
Input -WC- [5.1] DPT_Scaling 1 byte
No. Text Function Flags DPT type Size
