40 Transfer protocol
Room Controller Cala Touch KNX • Version: 13.07.2022 • Technical changes and errors excepted.
198 Temp. controller: Status cooling
level 2 (1=ON | 0=OFF)
Output R-CT [1.1] DPT_Switch 1 bit
199 Temp. controller: Comfort extension
status
Input/
Output
RWCT [1.1] DPT_Switch 1 bit
200 Temp. controller: Comfort extension
time
Input RWCT [7.005] DPT_-
TimePeriodSec
2 bytes
201 Temp. Controller: Fan coil level 0 to
3
Output R-CT [5.1] DPT_Scaling 1 byte
202 Temp. Controller: Fan coil level 1 Output R-CT [1.1] DPT_Switch 1 bit
203 Temp. Controller: Fan coil level 2 Output R-CT [1.1] DPT_Switch 1 bit
204 Temp. Controller: Fan coil level 3 Output R-CT [1.1] DPT_Switch 1 bit
205 Temp. Controller: Fan coil auto=1
manual=0
Input /
Output
RWCT [1.1] DPT_Switch 1 bit
Summer compensation (objects 209-211)
for all models
209 Summer compensation: Outdoor
temperature
Input -WCT [9.1] DPT_Val-
ue_Temp
2 bytes
210 Summer compensation: Target
value
Output R-CT [9.1] DPT_Val-
ue_Temp
2 bytes
211 Summer compensation: Block (1 =
Blocking)
Input -WC- [1.1] DPT_Switch 1 bit
Humidity sensor (objects 213-244)
for Cala KNX AQS/TH (item no. 70613, 70614), Cala KNX TH (item no. 70611, 70612),
213 Humidity sensor: Malfunction Output R-CT [1.1] DPT_Switch 1 bit
214 Humidity sensor: External measured
value
Input -WCT [9,007] DPT_Val-
ue_Humidity
2 bytes
215 Humidity sensor: Measured value Output R-CT [9,007] DPT_Val-
ue_Humidity
2 bytes
216 Humidity sensor: Measured value
total
Output R-CT [9,007] DPT_Val-
ue_Humidity
2 bytes
217 Humidity sensor: Measured value
min./max. query
Input -WC- [1.017] DPT_Trig-
ger
1 bit
218 Humidity sensor: Minimum
measured value
Output R-CT [9,007] DPT_Val-
ue_Humidity
2 bytes
219 Humidity sensor: Maximum
measured value
Output R-CT [9,007] DPT_Val-
ue_Humidity
2 bytes
220 Humidity sensor: measured value
min./max. reset
Input -WC- [1.017] DPT_Trig-
ger
1 bit
221 Humidity threshold value 1:
Absolute value
Input/
Output
RWCT [9,007] DPT_Val-
ue_Humidity
2 bytes
222 Humidity threshold value 1: (1:+ | 0:-) Input -WC- [1.1] DPT_Switch 1 bit
223 Humidity threshold value 1:
Delay from 0 to 1
Input -WC- [7.005] DPT_-
TimePeriodSec
2 bytes
No. Text Function Flags DPT type Size
