25 Setting the parameters

Cala KNX T 201/202 Sunblind Push Button • Version: 04.10.2021 • Technical changes and errors excepted

In case of a common control variable for heating and cooling, 0 is always transmitted

as a fixed value.

PI control with predetermined application:

This setting provides fixed parameters for frequent applications.

Now specify what should be sent when the control is blocked. Set a value greater 0

(=OFF) to receive a basic heating stage, e.g. for floor heating.

On release, the control variable follows the rule again.

In case of a common control variable for heating and cooling, 0 is always transmitted

as a fixed value.

2-point-control (only stage 2):

2-point-control is used for systems which are only set to ON or OFF.

Enter the hysteresis that prevents frequent on/off switching of temperatures in the

threshold range.

Control type • PI control

Setting of the controller by • Controller parameter

• specified applications

Application • Warm water heating

• Floor heating

• Convection unit

• Electric heating

Maximum control variable is reached

at setpoint/actual difference of (in °C)

Warm water heating: 5

Floor heating: 5

Convection unit: 4

Electric heating: 4

Reset time (in min.) Warm water heating: 150

Floor heating: 240

Convection unit: 90

Electric heating: 100

When blocked, the control variable should • not be sent

• send a specific value

Value (in %)

(only if a value is sent)

0...100

Control type

(is determined at a higher stage for com-

mon variables)

• 2-point-control

Hysteresis (in 0.1°C) 0...100; 20
