Cala KNX T 201/202 Sunblind push button • Version: 04.10.2021 • Technical changes and errors excepted.

2.3. Installation of the sensor

First install the windproof socket with feed line. Seal the inlet tubes as well, in order to

prevent draughts.

Then screw the base plate to the socket and place the switch program frame. Connect

the bus cable +/- to the plug (black-red).

Insert the device firmly onto the metal frame using the catches so that the device and

the housing are fixed together.

3. Commissioning

Never expose the device to water (e.g. rain) or dust. This can damage the electronics.

You must not exceed a relative humidity of 95%. Avoid condensation.

After the bus voltage has been applied, the device will enter an initialisation phase last-

ing a few seconds. During this phase no information can be received or sent via the

bus.

4. Addressing of the device at the bus

The device is supplied with the bus address 15.15.255. You can program another ad-

dress into the ETS by overwriting the 15.15.255 address or by teaching via the pro-

gramming button.

5. Display and operation at the device

5.1. Adjust room temperature (using the example

Cala KNX T 201 Sunblind)

Depending on the setting of the "Display mode" parameter in the device application,

the Cala KNX T 201/202 Sunblind push button displays the current room

temperature value (or mixed value), the target value or the shift in relation to the basic

setpoint. The display can be dimmed and switched off via the bus so that no value is

displayed.

Option A: Display of actual temperature (room temperature)

The current room temperature is displayed. It is not possible to change the room

temperature manually using the +/- buttons.

Option B: Display of target temperature or basic setpoint shift

Depending on the setting, the current target value or the shift relative to the base

setpoint is displayed. The temperature can be changed by touching the +/- buttons.
