User Manual
I
-
Series 3 Slate with Intel®
UM600706 Rev A, page 11 of 36
1. Mounting Bracket Release Latch
Sliding the latch to the right will release the mounting bracket from the Z30.
2. Power Connector (DC-IN)
To power up, plug the DC connector of the AC/DC power adaptor kit into the power connection on the device.
3. USB Type-C Port
The USB Type-C port allows connection to other type-C compatible devices (Up to 27W).
4. Cash Drawer Port (A/B)
The main cash drawer port is a RJ-12 interface and provides switchable operation at +12 Volts and +24 Volts. The default setting is at +24
Volts (0.5 Amps) and the settings are adjustable from the BIOS.
a. Cash Drawer Port Pin assignment
Pin# Signal Name Pin# Signal Name
1 GND 2 CD1-
3 CD1 Sense 4 CD Drive (+24/12V)
5 CD2- 6 Reserve
b. Switching between the +12 Volts and +24 Volts in Bios setting Manual
5. Ethernet LAN Port
The Ethernet LAN Port provides up to 1 Gbps speed capability for networking. Support wake on S3 only.
6. USB 3.0 Port (0.9A)
Two standard Super Speed USB 3.0 ports are available on the rear side.
7. +24 Volts Powered USB Port
The +24 Volts Powered USB Port is included on all models. The maximum power rating of the +24 Volts Powered USB is 24 Volts at 2.3
Amps.
