User Manual: 10 Series Monitor
UM600870 Rev C, page 12 of 26
Image Setting
Phase
Allow fine adjustments of the panel’s pixel dot clock phase.
Only applicable for VGA input video.
H. Position
Move the image horizontally on the display in single-pixel increments. Default: Centered
Only applicable for VGA input video.
V. Postion
Move the image vertically on the display in single-pixel increments. Default: Centered
Only applicable for VGA input video.
Image Ratio
Switch the scaling method between fill screen and original ratio settings. Default: Wide
Wide: Scales the X and Y dimensions of the input video (up or down as needed) to the display’s native resolution.
4:3: maintain the input video’s aspect ratio (and fills the rest of the display with equal black bars on the left and
right). Assuming a landscape orientation and an input video with an aspect ratio smaller than 16:9, scale the Y
dimension of the input video (up or down as needed) to the display’s Y resolution, scales the X-dimension.
Color Temp
Color Temp
Select the display’s color temperature. The available Color are Warm, Normal, Cool, User, and sRGB.
If the User option is selected, the user can change the color temperature by individually changing the gains
for red, green, and blue (ranging from 0 to 100, default setting with R, G, and B all set to 50).
Default: Warm.
OSD Setup
OSD H. Position Adjust the horizontal location of the OSD menus on the display. Default: Centered
OSD V. Position Adjust the vertical location of the OSD menus on the display. Default: Centered
OSD Timeout
Adjust how long a period of OSD inactivity the monitor will wait before closing the OSD. The adjustable range is
between 5 and 100 seconds.
Default: 10 seconds
Language
Select which language the OSD is displayed in. The available languages are English, French, Spanish, Simplified
Chinese, Traditional Chinese, Korean, Russian, Portuguese, Japanese
Default: English
Extra
Input Select
Select the input video source. The available options are Auto, D-Sub, HDMI, and Displayport.
Default: Auto
With the setting Auto:
The monitor continually scans for active video on the HDMI, D-Sub, and Display port connectors.
Reset
Restore all factory default settings for OSD-adjustable parameters (except OSD Language, R, G, B values in color
user setting, and input select setting).
Audio menu
(triggered by ‘Up’ button)
Volume
Adjust the audio volume. Default: 50
Audio will mute at volume 0.
Audio Source
Select the input audio source. The available options are Digital, Line in
Default: Digital
