UM600555 Rev B page 67 of 78
User Manual –i-series 4.0
General-purpose Input/Output (GPIO) Support
The I-Series 4.0 supports a GPIO which can be used to connect to peripherals such as a motion sensor.
Elo has an optional GPIO cable (PN: E211544) with flying leads so that it is easy for users to connect their
own peripherals.
Pinout of the GPIO cable (PN: E086398):
Red Wire: Pin 1 5 Volt output connection
White Wire: Pin 2 Input connection 1
Green Wire: Pin 3 Input connection 2
Two Black Wires: Pin 4 and Pin 5 are tied to ground
5V, 200mA is the max voltage and current available via this GPIO port.
G-Sensor
All I-Series 4.0 units are equipped with a g-sensor and will rotate the video based on the orientation of the device.
USB – C Settings
All i-series 4.0 device supports USB – C video, audio and touch via the USB- C cable.
The 15.6 and 22in i-series 4.0 device can also support power up to an Elo 1502L Touch monitor via the USB – C cable when using the Elo 90W power
supply.
