User Manual
–
IDS ET320
4
L/ET430
4
L/505
4L/5554L/6554L
UM6
00721
Rev
.
A
page
23
of
44
Parameter Available Adjustment
On Boot Up
Let’s Get Started
On first boot up, the Language, Time and Time Zone must be selected
Video
Aspect Ratio
Adjusts aspect ratio of the display.
Default: Fill Screen
Fill Screen:
scales the X- and Y-dimensions of the input video (up or down as needed) to the
display’s native resolution.
Fill Aspect Ratio:
Assuming a landscape orientation and an input video with aspect ratio smaller than
16:9, scales the Y-dimension of the input video (up or down as needed) to the
display’s Y-resolution, and scales the X-dimension to maintain the aspect ratio (and
fills the rest of the display with equal black bars on the left and right).
Direct Output:
1:1, Depends on whether the scalar can support it
Black Level
The user can choose between Standard, 5%, 10% or 15% black level offset.
The saturation level of the colors change according to the chosen black level offset.
Brightness
Adjust the brightness of the display.
Contrast
Adjust the contrast of the display.
Default: 50
Sharpness
Adjusts sharpness of the displayed images.
Default: no sharpness adjustment
Sharpness function is disabled when the input source ratio is the same as the panel’s
native ratio
Video Port
Discovery
When enabled, the monitor will automatically switch if a new video port is connected.
Default: Enabled
Brightness
Sensor
The light sensor can be toggled on or off. When the light sensor is enabled, the
brightness cannot be changed manually.
Table for light sensor is in Section 10: Appendix A
