User Manual
–
IDS ET320
4
L/ET430
4
L/505
4L/5554L/6554L
UM6
00721
Rev
.
A
page
20
of
44
Rear VESA Mount
A four-hole, VESA mounting pattern is provided on the rear of the IDS Display. The VESA FDMI-compliant mounting is coded:
- ET3204L : MIS-F, 400, Y, 6mm x 18mm (4 screws M6x15mm)
- ET4304L : MIS-F, 400, Y, 6mm x 25mm (4 screws M6x15mm)
- ET5054L : MIS-F, 400, Y, 6mm x 23mm (4 screws M6x15mm)
- ET5554L : MIS-F, 400, Y, 6mm x 25mm (4 screws M6x15mm)
- ET6554L : MIS-F, 600, Y, 8mm x 18mm (4 screws M6x15mm)
Refer to www.elotouch.com for dimensional drawings.
Optional Mounting Methods
An optional stand kit and low-profile wall-mount kit are available for the IDS ET3204L/ET4304L/ET5054L/ET5554L/ET6554L
Displays. Detailed information is available on the marketing specification drawing at www.elotouch.com. Consult each kits user
guide for detailed installation information.
Elo Stand kit:
Elo Part Number: E722153, Includes mounting screws M6x20mm (x4), and M6x55mm (x4)
Drawing Numbers: MS603258 / MS603259 / MS603260 for IDS ET3204L/ET4304L/ET5054L
Elo Low Profile Wall Mount kit:
Elo Part Number: E721949, Includes mounting screws M4x10mm (x2), M6x15mm (x4)
Drawing Numbers: MS602351/ MS602352/ MS602353 for IDS ET3204L/ET4304L/ET5054L
Elo Low Profile Wall Mount kit:
Elo Part Number: E727774, Includes mounting screws M4x16mm (x2), M8x25mm (x4) and M8x40mm (x4)
Drawing Numbers: MS603261 / MS603262 for IDS ET5554L/ET6554L
