User Manual: Interactive Digital Signage
SW601990 Rev K, Page 6 of 37
Chapter 3: IDS Touchmonitor Installation
Connector Panel & Interfaces
Note: For your health and safety, it is strongly recommended that at
least two people (four for the ET7001L/ET7001LT) handle, lift, or move
these Touchmonitors. Elo recommends safe lifting techniques as
described in OSHA/NIOSH Guidelines.
Check that the following items are present and in good condition:
IDS touchmonitor
User Manual CD
Quick Install Guide
OSD Remote connected to the monitor
Cables
o HDMI, USB, North America power, Europe/Korea power, U.K. power, Argentina power,
Taiwan power, China power, Korea power, Japan power, & Japan 3pin-2pin adapter and
VGA cable for the Y-Cable (7001LT).
The Y-Cable is used to send MDC to the monitor. For more information about
MDC commands, see page 20.
Remove the cable cover on the bottom rear (when viewed in landscape orientation) to access
the touchmonitors connector panel.
Pictures of the connector panel and interfaces. The OSD connection is in red.
3201L/4201L/5501L/7001L/ET7001LT
Images of monitor back I/O ports with OSD remote
