User Manual: Interactive Digital Signage
SW602296 Rev C, Page 13 of 39
Chapter 5: Operation
Power
To turn the touch display on or off, press the touch display power button once. If a computer
module is installed, then the computer module will also turn on with the monitor.
To gracefully shut down the computer module, follow the computer modules operating systems
normal power off procedure.
The system consumes low power when in SLEEP and OFF modes. For detailed power
consumption specifications, refer to technical specifications available on the Elo website
www.elotouch.com.
Touching the screen will bring the system out of MONITOR SLEEP mode.
If long periods of disuse are planned, unplug the AC power cable to save power.
The maximum voltage, frequency and current for the touch display are provided in the power
ratings table below:
Operating Voltage
Range
Operating Frequency
Range
Operating Current
Rating
100 - 240Vac 50/60 Hz 1.8 A
Usage Duty Cycle
Product Family Required maximum usage duty cycle
3202L 18 hours per day (each 24 hours)
4202L N/A
4602L 20 hours per day (each 24 hours)
In order to save energy and extend life of the display, Elo recommends shutting off the display
when not in use. A number of tools, such as Content Management System (CMS) player
applications, Operating System settings, On-Screen Display Menu (OSD) within the IDS display
can be used for this task.
