© 2014 Elo Touch Solutions, Inc. All rights reserved.
03/14
www.elotouch.com
North America
Elo Touch Solutions
Europe
Latin America
Model 4243L
Color Black
Active Display Area 36.6” x 20.6” (930 mm x 523 mm)
Dimensions
*
38.5” x 2.6” x 22.6” (978mm x 65mm x 575mm) max
LCD Technology Active matrix TFT LCD with LED backlight
On-Screen Display (OSD)
Accessible through switches on the OSD Control Remote accessory. Controls: Menu, Up, Down,
Select; Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect
Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Source;
Japanese; Lockouts: OSD, Power
Mounting Options
*
VESA 4-hole mount per MIS-F, 400, 400, 6mm (side mounting brackets included with unit)
Aspect Ratio 16:9
Native Resolution 1920 x 1080
Preset Video Timings
640x480 60Hz, 720x480 60Hz, 720x576 50Hz, 800x600 56Hz, 1024x768 60Hz,1280x720 50Hz, 1280x720
60Hz, 1280x960 60Hz, 1280x1024 60Hz, 1440x900 60Hz, 1366x768 60Hz, 1680x1050 60Hz, 1920x1080 50Hz,
1920x1080 60Hz
Number of Colors 1073 million
Brightness (typical)
LCD Panel
IntelliTouch Plus
No Touch
500 nits
450 nits
450 nits
Response Time (Tr + Tf) (typical) 8 ms
Viewing Angle (typical) Horizontal: ±89°; Vertical: ±89°
Contrast Ratio (typical) 4000:1
Video
Analog VGA on Female DE-15 connector; HDCP-capable HDMI 1.3 on HDMI Type A receptacle
connector (ET4243L-XXWA models only); Digital DVI on Female DVI-D, Dual-Link connector
(ET4243L-XXAA models only). Input Video Horizontal Sync frequency range: 31.5-75KHz, Input Video
Vertical Sync (frame rate) frequency range: 47-63Hz
Power
Monitor Only - Power Consumption: (typical at 110V at 60Hz): ON: 105W; SLEEP: 7W; OFF: 5.5W; Monitor
Only - Power Consumption: (typical at 230V at 50Hz): ON: 101W; SLEEP: 6W; OFF: 5.0W;
Weight
Unpackaged— 44 lbs. (20kg)
Packaged: 61 lbs. (27.67kg)
Shipping Dimensions 45.9”x 33.7” x 11.02” (1168 mm x 856 mm x 280 mm)
Temperature Operating: 32°F to 104°F (0°C to 40°C); Storage: -4°F to 140°F (-20°C to 50°C)
Humidity (non-condensing) Operating: 20%-80%; Storage: 10%-95%
Regulatory approvals and declarations
UL, FCC; cUL, IC; CB; CE; VCCI; C-Tick; NOM CoC; GOST; BSMI; KC,
e-Standby; CCC, China RoHS, UL60950
Warranty 3 years standard
MTBF 50,000 hours demonstrated
4243L 42” LCD Open-frame Touchmonitor
Model
Part
Number
Technology Interface Surface Treatment Availability
4243L E000444 IntelliTouch Plus, VGA & HDMI USB Clear Worldwide
4243L E000445 IntelliTouch Plus, VGA & DVI USB Clear Asia
4243L E000447 No Touch, VGA & HDMI USB Clear Worldwide
Peripheral Part Number
Cable Kit for Replacement Cables E378229
Remote On-Screen Display (OSD) E483757
Ordering Information
*
See dimensional drawings for details
