Model 3243L
Color Black
Active Display Area 27.49” x 15.47” (698.4mm x 392.85mm)
Dimensions* 28.95” x 17.44” x 2.28” (735.4mm x 443mm x 58mm) max
LCD Technology Active matrix TFT LCD
Diagonal Size 31.5"
On-Screen Display (OSD)
Accessible through switches on the OSD Control Remote accessory. Controls: Menu, Up, Down, Select; Settings:
Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature,
OSD Timeout, OSD Language, Recall Defaults, Video Source; Languages: English, French, Italian, German,
Mounting Options*
400mm x 200mm VESA 4-hole mounting interface on rear of unit
Side mounting brackets included with unit
Aspect Ratio 16:9
Native Resolution 1920 x 1080
Preset Video Timings
640x480 60Hz, 800x500 60Hz, 800x600 56, 60Hz, 1024x768 60Hz, 1280x720 60Hz, 1280x960 60Hz, 1280x1024 60Hz,
1360x768 60Hz, 1366x768 60Hz, 1440x900 60Hz, 1600x1200 60Hz, 1680x1050 60Hz, 1920x1080 60Hz
Number of Colors 16.7 million
Brightness (typical) LCD Panel: 350 nits; with Non-Touch: 315 nits; with IntelliTouch Plus: 315 nits
Response Time (Tr + Tf) (typical) 8 ms
Viewing Angle (typical) Horizontal: 178°; Vertical: 178°
Contrast Ratio (typical) 3000:1
Video
Analog VGA on Female DE-15 connector; HDCP-capable HDMI 1.3 on HDMI Type A receptacle connector
(ET3243L-XXWA models only); Digital DVI on Female DVI-D, Dual-Link connector (ET3243L-XXAA models only)
Input Video Horizontal Sync frequency range: 31.5-80KHz
Input Video Vertical Sync (frame rate) frequency range: 47-63Hz
Power
Power Consumption (Typical): ON (monitor + AC/DC adapter): 55W; SLEEP (monitor + AC/DC adapter): 1.4W; OFF
(monitor + AC/DC adapter): 0.3W
Weight Unpackaged: 27.12 lbs (12.3kg); Packaged: 41.5 lbs (18.8kg)
Shipping Dimensions 39.05” x 26.45” x 11.65” (992mm x 672mm x 296mm)
Temperature Operating: 32°F to 104°F (0°C to 40°C); Storage: (-4°F to 140°F) -20°C to 60°C
Humidity (non-condensing) Operating: 20%-80%; Storage: 10%-90%
Regulatory approvals and
declarations
S-Mark; C-Tick; CUL, IC; CCC; CE; VCCI; KC, KCC, e-Standby; CoC; GOST; BSMI; UL, FCC; CB; RoHS, China RoHS,
WEEE; UL60950
Warranty 3 year standard
MTBF 50,000 hours demonstrated
Ordering Information
Model Part Number
Technology Interface Surface Treatment Availability
3243L
E589724 IntelliTouch Plus USB Clear Worldwide
E444804 IntelliTouch Plus USB Clear Asia
Peripheral Part Number
Cable Kit for Replacement Cables E378229
Remote On-Screen Display (OSD) E483757
3243L 32” LCD Open-frame Touchmonitor
