Ordering Information
Part Number Technology Interface Input Video Format Surface Treatment
E237584 IntelliTouch Plus USB DVI/Analog VGA Clear
E059181 IntelliTouch USB DVI/Analog VGA Clear
E811441 Projected Capacitive USB DVI/Analog VGA Clear
E378034 SecureTouch USB DVI/Analog VGA Clear
© 2014 Elo Touch Solutions, Inc. All rights reserved.
05/14
www.elotouch.com
North America
Elo Touch Solutions
800 -ELO-TOUCH
Europe
Latin America
Model 2243L
Bezel Color Black
Diagonal Size 21.5” diagonal
Aspect Ratio 16:9
Active Display Area 18.8” x 10.6” (477mm x 268mm)
Dimensions* 20.2” x 11.7” x 1.7” (512mm x 298mm x 43mm) max
LCD Technology Active matrix TFT LCD with LED backlighting
Native Resolution 1920 x 1080
Other Supported Resolutions
640x480 60Hz; 720x576 50Hz; 800x600 56, 60Hz; 1024x768 60Hz; 1280x720 50, 60Hz; 1280x960 60Hz; 1280x1024 60Hz;
1366x768 60Hz; 1440x900 60Hz; 1680x1050 60Hz; 1920x1080 50, 60Hz
Colors 16.7 million
Brightness (Typical)
LCD Panel: 250 nits; with IntelliTouch: 225 nits; with IntelliTouch Plus:
225 nits; with PCAP: 225 nits; SecureTouch: 225 nits
On-Screen Display (OSD) Accessible through switches on the unit’s tethered OSD Control box.
Controls: Menu, Up, Down, Select; Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust,
Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD; V-Position,
Chinese, Japanese; Lockouts: OSD, Power
Response Time ((Tr + Tf) (Typical) 5 ms
Viewing Angle (Typical) Horizontal: ±85°; Vertical: ±80°
Contrast Ratio (Typical) 1000:1
Video
Analog VGA on Female DE-15 connector; Digital DVI on Female DVI-D connector; Input Video Horizontal Sync
frequency range: 31.5-80KHz; Input Video Vertical Sync (frame rate) frequency range: 50-75Hz
Power External DC—optional power brick (sold separately)
Monitor input power connector: Coaxial power jack (2mm pin outer diameter, 6.4mm barrel inner diameter);
Adapter input connector: IEC 60320 C14; Adapter input voltage range: 100-240VAC, 50/60Hz
Power Consumption (typical): ON (monitor only): 22W;
ON (monitor + AC/DC adapter at 230V/50Hz): 25W
SLEEP (monitor + AC/DC adapter at 230V/50Hz): 2.2W
OFF (monitor + AC/DC adapter at 230V/50Hz): 1.1W
Temperature Operating: 32°F to 104°F (0°C to 40°C); Storage: (-4°F to 140°F) -20°C to 60°C
Humidity (Non-Condensing)
Weight Unpackaged: 10.6lbs (4.8kg); Packaged: 15.3lbs (6.9kg)
Shipping Dimensions 7.9” x 24.4” x 16.9” (200mm x 620mm x 430mm)
Warranty 3 years
MTBF 50,000 hours demonstrated
User’s Controls Optional remote OSD: Auto/Sel, up, down, menu; OSD buttons: menu, left, right, select, power; OSD: contrast,
brightness, H/V position, RGB (color temp), clock, phase, recall, language (English, German, Spanish, Japanese,
French); OSD disable/enable: power, OSD menu
Mounting Options*
VESA 4-hole 100mm mounting interface on rear of unit
2-hole mounting interface on all 4 sides
Regulatory Approvals and
Declarations
S-Mark; C-Tick; cUL, IC; CCC; CE; VCCI; KCC; NOM; BSMI; UL, FCC; CB; RoHS, China RoHS, WEEE, IMERC
*See dimensional drawings for details
