Ordering Information
Model
Part Number Technology Interface Surface Treatment Availability
2239L
E654071 IntelliTouch Dual serial/USB Antiglare Americas
E230376 IntelliTouch Dual Serial/USB Clear Americas
E523763 IntelliTouch Dual serial/USB Clear
E629432 IntelliTouch Dual serial/USB Antiglare
E807682 IntelliTouch Dual serial/USB Antiglare EMEA
E846997 IntelliTouch Dual serial/USB Clear EMEA
© 2014 Elo Touch Solutions, Inc. All rights reserved.
03/14
www.elotouch.com
North America
Elo Touch Solutions
800-ELO-TOUCH
Europe
Latin America
Case/Bezel Color Dark gray
Display Type Active matrix TFT LCD
Display Size 22.0” diagonal
Useful Screen Area
Horizontal: 473.8 mm
Vertical: 296.1 mm
Monitor Dimensions
Width: 530 mm
Height: 352 mm
Depth: 78 mm
Optimal (Pre-Set) Resolution 1680 x 1050 @ 60 Hz (90 pixels/inch)
Other Supported Resolutions
640 x 480 @ 60 Hz, 640 x 480 @ 66 Hz, 640 x 480 @ 72 Hz, 720 x 350 @ 70 Hz, 720 x 400 @ 70 Hz, 800 x 500
@ 75 Hz, 800 x 600 @ 56 Hz, 800 x 600 @ 60 Hz, 800 x 600 @ 72Hz, 832 x 624 @ 75 Hz, 1024 x 768 @ 60 Hz,
1024 x 768 @ 65 Hz, 1024 x 768 @ 72Hz, 1024 x 768 @ 75 Hz, 1152 x 864 @ 75 Hz, 1280 x 960 @ 60 Hz,
1280 x 1024 @ 60 Hz, 1280 x 768 @ 65 Hz, 1280 x 1024 @ 75 Hz, 1360 x 768 @ 60 Hz, 1366 x 768 @ 60 Hz;
1600 x 1200 @ 60 Hz, 1680 x 1050 @ 75 Hz
Colors 16.7 million colors
Brightness (typical) LCD Panel: 300 cd/m
2
, min. 250 cd/m
2
with IntelliTouch: 270 cd/m
2
, min. 212 cd/m
2
Response Time Typical Rise Time 5 msec; Typical Fall Time 5 msec
Viewing Angle (typical)
Horizontal: 170° at a CR>10
Vertical: 160° at a CR>10
Contrast Ratio 1000:1 (typical)
Input Video Format
1. RGB Analog Video
2. DVI Video (not available on 2239L-xxxx-x-A-x) models
Input Sync Format Separate H & V sync, Composite Sync, and Sync-On-Green
Input Video Signal Connector
1. 15-pin female D-sub for Analog Video
2. Female DVI-D for Digital Video
Scanning Frequency Ranges
Horizontal: 30 - 75 kHz
Vertical: 56 - 75 Hz
Power Consumption 50W typical, 75W maximum (at 120V/60Hz input)
Power Supply - Internal Monitor Input Voltage: 100~240 VAC, 50/60Hz
Temperature
Operating: 0°C to 40°C
Storage: -20°C to 60°C
Humidity
Operating: 20% to 80% humidity (non-condensing)
Storage: 10% to 90% humidity (non-condensing
Monitor MTBF (excluding lamps) 50,000 hours demonstrated
Backlight Lamp Life 50,000 hours (typical); 40,000 minimum
Weight (approx.) Actual: 8.48 kg; Shipping: 12.59 kg
Other Features
100 mm VESA mount; Digital on-screen display (OSD); User’s control: OSD buttons: menu, up,
down, select; OSD: automatic adjustment, contrast, brightness, H/V position, clock, phase, color
temperature, input video select, OSD H/V position, OSD timeout, language (English, French, Italian,
sharpness, display information; OSD locking/unlocking and power locking/unlocking
Warranty TouchMonitor: 3 years
Touch Interface USB and Serial (IntelliTouch)
UL (US), cUL (Canada), GS Mark (Germany), FCC (US), CE (EU), NOM (Mexico), PCT (Russia), CCC/
RoHS (China), eK/Mic (Korea), BSMI (Taiwan), Singapore, VCCI (Japan), C-Tick (Australia) and S-mark
(Argentina), WEEE, IMERC.
2239L 22” Open-Frame Wide-Aspect LCD Touchmonitor
