North America
Elo Touch Solutions
800-ELO-TOUCH
Europe
Latin America
Model 1940L
Active Display Area 16.13” x 9.07” (409.8mm x 230.4mm)
Dimensions 17.58” x 10.58” x 1.51” (446.7mm x 268.8mm x 38.5mm) max
LCD Technology Active matrix TFT LCD with LED backlighting
Diagonal Size 18.5”
On-Screen Display (OSD)
Accessible through switches on the unit’s tethered OSD Control Keypad.
Controls: Menu, Up, Down, Select, Power
Settings: Brightness, Contrast, Clock, Phase, H-position, Vposition, Auto-Adjust,
Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position,
OSD V-Position,Recall Defaults, Video Source
Lockouts: OSD, Power
Mounting Options* VESA 4-hole 75mm mounting interface on rear of unit; 2-hole mounting interface on all 4 sides
Native Resolution 1366x768
Aspect Ratio 16:9
Preset Video Timings
720 x 350 at 70Hz; 720 x 400 at 70Hz; 640 x 480 at 60, 72, 75Hz; 800 x 600 at 56, 60, 72, 75Hz;
800 x 500 at 60Hz; 832 x 624 at 75Hz; 1024 x 768 at 60, 70, 75Hz; 1280 x 800 at 60Hz; 1280 x 960 at 60Hz;
1280 x 1024 at 60, 75Hz; 1366 x 768 at 60Hz
Number of Colors 16.7 million
Brightness (typical) LCD Panel: 250 nits; with IntelliTouch Plus: 225 nits; with PCAP: 225 nits
Response Time (Tr + Tf) (typical) 5 ms
Viewing Angle (typical) Horizontal: 170°; Vertical: 160°
Contrast Ratio (typical) 1000:1
Video
Analog VGA on Female DE-15 connector; Digital DVI on Female DVI-D connector Input Video Horizontal
Sync frequency range: 31.5-80KHz Input Video Vertical Sync (frame rate) frequency range: 50-75Hz
Power
External DC—optional power brick (sold separately)
Monitor input power connector: Coaxial power jack
(2mm pin outer diameter, 6.4mm barrel inner diameter)
Adapter input connector: IEC 60320 C14
Adapter input voltage range: 100-240VAC, 50/60Hz
Power Consumption: ON (monitor + AC/DC adapter at 230V/50Hz): 19W(typ), 25W (max); SLEEP
(monitor + AC/DC adapter at 230V/50Hz): 2.0W; OFF (monitor + AC/DC adapter at 230V/50Hz): 1.0W
Audio N/A (No audio functionality)
Weight Unpackaged: 7.38 lbs (3.35kg); Packaged: 10.58 lbs (4.8kg)
Shipping Dimensions 21.45” (L) x 14.37” (W) x 5.5” (H) (54.5cm x 36.5cm x 14cm)
Temperature Operating: 32°F to 104°F (0°C to 40°C); Storage: -4°F to 140°F (-20°C to 60°C)
Humidity (non-condensing) Operating: 20%-80%; Storage: 10%-90%
Regulatory approvals and declarations C-Tick, cUL, IC, CCC, CE, VCCI, KCC, CoC, BSMI; UL, FCC; CB, RoHS, WEEE, IMERC
Warranty 3 years
MTBF 50,000 hours demonstrated
1940L 19” LED Open-Frame Touchmonitor
Model Part Number Technology Interface Surface Treatment Availability
1940L
E855244 IntelliTouch Plus USB Clear Worldwide
E065303 Projected Capacitive USB Clear Worldwide
Ordering Information
*See dimensional drawings for details.
