© 2014 Elo Touch Solutions, Inc. All rights reserved.
12/14
www.elotouch.com
North America
Elo Touch Solutions
800-ELO-TOUCH
Europe
Latin America
Case/Bezel Color Steel/black
Display
Size: 17.0” diagonal
Type: Active matrix TFT LCD with LED backlighting
Aspect ratio: 5:4
Useful Screen Area Horizontal: 13.3” (338 mm); Vertical: 10.6” (270 mm)
Monitor Dimensions
Width: 14.5” (368 mm)
Height: 12.0” (306 mm)
Depth: 1.9” (49 mm)
Optimal (native) Resolution 1280 x 1024
Colors 16.7 million
Brightness (typical)
LCD panel: 250 nits; AccuTouch: 200 nits; CarrollTouch: 225 nits; IntelliTouch: 225 nits;
IntelliTouch Plus: 225 nits; SecureTouch: 220 nits
Response Time (typical) 5msec
Viewing Angle (typical, from center)
Horizontal (left/right): ±85° or 170° total
Vertical (up/down): ±80° or 160° total
Contrast Ratio (typical) 1000:1
Input Video Format Analog VGA and digital DVI
Input Video Signal Connector Female DE-15 connector, Female DVI-D, Dual-Link connector
Input Frequency Horizontal: 31.5-80.0 kHz; Vertical: 56.3-75 Hz
Power
External DC—optional power brick (sold separately)
Input voltage—DC: +12VDC ±5% at 2.5 A max.
diameter: 6.4 mm (±0.3 mm); Pin outer diameter: 2.0 mm (+0.0 -0.1 mm); Barrel depth: 8.8 mm (±0.3 mm)
Power connector (on power brick)—Type: DC Barrel Plug; Barrel outer diameter: 5.5 mm
(±0.1 mm); Pin inner diameter: 2.1 mm (±0.1 mm); Barrel length: 9.5 mm (±0.5 mm)
Power Consumption (typical)
Monitor only: 20W
Monitor and power brick: 22W
Temperature Operating: 0°C to 40°C; Storage: -20°C to 60°C
Humidity (noncondensing) Operating: 20%-80%; Storage: 10%-90
Weight (approx.) Actual: 8.8 lb (4.0 kg); Shipping: 11.5 lb (5.2 kg)
Warranty 3 years
MTBF 50,000 hours demonstrated
Agency Approvals UL/cUL (Recognized), TUV T-Mark, CE,FCC,VCCI,IC,C-TICK (Class B), BSMI, KC, CCC, China RoHS
On-screen display (OSD) Digital OSD or optional remote OSD with 1.8 m cable
User’s Controls
Optional remote OSD: Auto/Sel, up, down, menu
OSD buttons: menu, left, right, select, power
OSD: contrast, brightness, H/V position, RGB (color temp), clock, phase, recall, language
OSD disable/enable: power, OSD menu
Mounting Options
75 mm or 100 mm VESA mount
Rear mount includes standard mounting brackets
Front mount with optional bezel
Rack mount with optional bracket
Model Part Number Technology Interface Surface Treatment Availability
1739L
E607940 AccuTouch Dual serial/USB Antiglare Worldwide
E964551 CarrollTouch Dual Serial/USB Antiglare Worldwide
E012584 IntelliTouch Dual serial/USB Antiglare Worldwide
E734455 SecureTouch Dual serial/USB Antiglare Worldwide
E575274 IntelliTouch Plus USB Clear Worldwide
Ordering Information
