User Manual – 1929LM
SW200158 Rev B - Page 21 of 31
Auto Adjust
Automatically adjusts the system clock to the input analog VGA video signal, affecting
the H-position, V-position, Clock, and Phase menu items.
Only applicable for VGA input video
H-position
Moves the image horizontally on the display in single-pixel increments.
Default: centered.
Only applicable for VGA input video
V-position
Moves the image vertically on the display in single-pixel increments.
Default: centered.
Only applicable for VGA input video
Aspect Ratio
Switches the scaling method between Full Scaling and Maintain Aspect Ratio.
Default: Full Scaling
Full Scaling – scales the X- and Y-dimensions of the input video (up or down as
needed) to the display’s native resolution.
Fill To Aspect Ratio – Assuming a landscape orientation and an input video with
aspect ratio smaller than 1280x1024, scales the Y-dimension of the input video (up or
down as needed) to the display’s Y-resolution, and scales the X-dimension to maintain
the input video’s aspect ratio (and fills the rest of the display with equal black bars on
the left and right).
APR touchscreen functionality is only guaranteed at full scaling. Other touchscreen
technologies may need recalibration when switching between Aspect Ratio options.
Sharpness
Adjusts sharpness of the displayed images.
Default: no sharpness adjustment
Only applicable at non-native input video resolutions
Color
Temperature
Selects the display’s color temperature. The available color temperatures are 9300K,
7500K, 6500K, 5500K, and User Defined. If the User Defined option is selected, the
user can change the color temperature by changing individual R, G, and B gains on a
scale from 0 to 100.
Default: User Defined with R, G, and B all set to 100.
OSD Timeout
Adjusts how long a period of OSD button inactivity the touchmonitor will wait before
closing the OSD. The adjustable range is between 5 and 60 seconds.
Default: 15 seconds
OSD
Language
Selects which language the OSD information is displayed in. The available
languages are: English, French, German, Italian, Spanish, Japanese, Traditional
Chinese, Simplified Chinese, Polish and Russian.
Default: English.
Information
Display monitor PN&SN information.
Power Off 5s
Timer
Enables power key off delay function ( 5 sec countdown)
Audio source
Selects audio source. The available audio sources are “From Video Source” and “Line-in”.
Volume
Adjusts the volume of the internal speakers and headphone output.
Mute
Toggles the audio output between Muted and Not Muted.
Default: Not Muted
Recall
Defaults
Selecting “Recall Defaults” restores all factory default settings for OSD-adjustable
parameters (except OSD Language) and for Preset Video Mode timings.
Input Select
The monitor continually scans for active video on the VGA ,HDMI and DisplayPort
connectors. This adjustment selects which of those input ports should be given priority
to be displayed.
The options are: VGA Priority, HDMI Priority, DisplayPort Priority
Default: VGA Priority
