20
Setting the spool of thread
Lift up the spool pin. Place the spool of thread on the
spool pin.
Attach the spool holder (large), and press it rmly against
the spool of thread.
(1) Spool holder (large)
Winding the Bobbin
Removing the Bobbin
Press the lockout key.
Slide the hook cover release button to the right, and
remove the hook cover plate.
(1) Hook cover release button
(2) Hook cover plate
Lift out the bobbin from the bobbin holder.
(3) Bobbin
Use the spool holder (small) to hold narrow or small
spools of thread.
(2) Spool holder (small)
(4)
(1)
(2)
(3)
(3)
Use the spool holder (special) to hold the specic size of
the spool of threads as shown.
The sizes of the spools of thread are as follows;
The hole diameter of the spool has a range of 3/8˝ to
7/16˝ (9.5 mm to 10.5 mm), and the spool length has a
range of 2 3/4˝ to 3˝ (70 mm to 75 mm).
(3) Spool holder (special)
(4) Hole diameter (3/8˝ to 7/16˝)
(5) Spool length (2 3/4˝ to 3˝)
Firmly insert the spool holder (special) into the hole and
hold the spool as illustrated.
(4)
(4)
(5)
(1)
(2)
(3)
(2)
(1)
(3)
NOTE:
• Use “J” plastic bobbins (4) for the horizontal hook.
Using other bobbins, such as pre-wound paper
bobbins, may cause stitching problems and/or damage
to the bobbin holder.
• Do not use the easy bobbin or metal bobbins.
Extra spool pin
Use the extra spool pin when you need to wind a bobbin
without unthreading the machine while working on a
sewing project (refer to page 21).
Insert the extra spool pin into the hole as shown.
Place a spool of thread on the extra spool pin and x the
spool with the spool holder.
(1) Extra spool pin
(2) Hole for extra spool pin
(3) Spool holder
NOTE:
The extra spool pin is also used for twin needle
sewing.
