21
Threading the Machine
Raise the presser foot lifter to raise the presser foot.
Turn the power switch on.
Press the needle up/down button to raise the take-up
lever to the highest position.
Press the lockout key or turn the power switch off.
Pass the thread in the order from
z
to
,
.
CAUTION:
Always make sure to press the lockout key to lockout
the machine or turn the power switch off before
threading the machine.
z Hold the thread with both hands and pass the thread
into the guide slot.
q Guide slot
x Be sure that the thread is pulled down under the notch
and into the space below the guide slot as shown.
w Notch
c Hold the thread with both hands and draw the thread
around the corner of the guide.
Firmly pull the thread toward you along the right
channel until the thread snaps.
e Corner of the guide
r Right channel
v Draw the thread down along the right channel and
around the bottom of the thread guide plate. Pull the
thread up along the left channel.
r Right channel
t Thread guide plate
y Left channel
b While holding the thread at the spool, rmly draw the
thread up and to the back of the take-up lever. Draw
the thread forward to slip it into the eye of the take-up
lever.
u Eye of the take-up lever
r
y
t
u
i
o
v
b
n m ,
c
e
r
x
w
q
z
v
z x
c
b
n
m
,
n Then pull the thread down along the left channel and
through the lower thread guide.
i Lower thread guide
m Slide the thread behind the needle bar thread guide
on the left.
o Needle bar thread guide
, Thread the needle with the needle threader (refer to
the next page).
