75
Press the stitch width adjusting key to adjust the stitch
width.
NOTE:
Stitch length can be uniformly adjusted if the
programmed patterns in the same category (satin
stitches or stretch stitches) have been programmed.
The stitch width of the programmed patterns will be
adjusted uniformly.
q Original width
w Uniformly adjusted width
Uniform Stitch Adjustment
The stitch width and length of the programmed patterns
can be uniformly adjusted.
Example: Adjusting the stitch width of the programmed
pattern 39 (mode 2) and its mirror image.
Unied Needle Drop Position
The needle drop position of the programmed patterns will
vary depending on the pattern combination:
(A) Unied to the left when combining the patterns with
the left needle position and the center needle
position.
(B) Unied to the right when combining the patterns with
the center needle position and the right needle
position.
(C) Unied to the center when combining the patterns
with the left needle position and the right needle
position.
(D) Unied to the center when combining the patterns
with the left, center and right needle positions.
q w
(A) (B) (C) (D)
Shift the cursor to the right of the last programmed
pattern.
