EN

22

III. STEREO SETUP

3c. Positioning the PF14LCR speaker behind a projection screen

If you have an acoustically transparent screen, we recommend to install the loudspeakers a

third of the way down from the top of the screen. Use the middle of the speaker as a reference

point (middle of the tweeter). For this conguration, we recommend removing the grills from

the speakers.

1/3

1/3

1/3

1. Position of the speakers FL/FR

The Prestige Facet loudspeakers have been designed to reproduce all types of music

as accurately as possible, provided that a few rules should be followed to optimize

performance and achieve a realistic sound image.

Ideally, the speakers should be placed symmetrically in front of the listening position to form

an equilateral triangle. The cabinets should be placed at the same height and the same

distance from the rear wall and the adjacent side surfaces.

In order to optimize the setup of the speakers in your listening room, we recommend the

following tests :

•Above all, you should avoid positioning the loudspeakers in the corners of your room. The

result will be an articial increase in the level of bass, masking the speed and details of

this range.

•First, adjust the spacing of the two speakers in order to nd the realistic balance between

a wide sound image (wide apart speakers) and a sound image respecting the punctuality

2. Connections

It is essential to connect the speakers using the correct polarity. Make sure to connect the

“ + ” terminal of the speaker (Red) to the “ + ” output terminal of the amplier. Then, make

sure to connect the “ - ” terminal of the speaker (Black) to the “ - ” output terminal of the

amplier. A wrong connection would cause a cribled stereo image and loss of bass. Use

high quality speaker cable. Elipson speakers are supplied congured for use in a single

wired mode or bi-wiring. Bi-amp is also possible (see page 31).

ALL THE CONNECTIONS MUST BE MADE WITH THE EQUIPMENT TURNED OFF.

of the voices (close speakers).

•Secondly, move the speakers away from the rear wall by steps of 10 cm to nd the

balance between the depth of the sound image (far from the back wall) and the level of

the extreme low frequencies (close to the back wall).

•Finally, adjust the loudspeakers orientation by turning them gradually toward the center

of the listening area. If you leave the speakers parallel, you may want to bring them closer

together, if you orient them more than 30°, you may increase their spacing.

~60°

> 30cm

> 30cm

•FR

•FL
