Eliminator Lighting - www.eliminatorlighting.com - Tri Disc 9 IR User Manual - Page 15 Eliminator Lighting - www.eliminatorlighting.com - Tri Disc 9 IR User Manual - Page 16

Channel Value Function

6 PROGRAMS/SOUND ACTIVITY

168 - 175 SOUND MODE 5

176 - 183 SOUND MODE 6

184 - 191 SOUND MODE 7

192 - 199 SOUND MODE 8

200 - 207 SOUND MODE 9

208 - 215 SOUND MODE 10

216 - 223 SOUND MODE 11

224 - 231 SOUND MODE 12

232 - 239 SOUND MODE 13

240 - 247 SOUND MODE 14

248 - 255 SOUND MODE 15

7 MASTER DIMMER

1 - 255 0% - 100%

Tri Disc 9 IR 7 Channel - DMX Values & Functions

Channels 1, 2, and 3 will not work, when Channel 4 is being used.

When using Channel 6 values 8-135, Channel 5 will control the speed of the programs.

When using Channel 6 values 136-255, Channel 5 will control the sound sensitivity. Sound sen-

sitivity control will start working after Channel 5 is past the DMX value of 31.

Channel Value Function

1 RED

1 - 255 0% - 100%

2 GREEN

1 - 255 0% - 100%

3 BLUE

1 - 255 0% - 100%

4 1 - 255 COLOR MACROS

(See 1 Channel DMX mode for colors)

5 STROBING/PROGRAM SPEED

0 - 15 NOTHING

16 - 255 STROBING/SPEED CONTROL

SLOW - FAST

6 PROGRAMS/SOUND ACTIVITY

0 - 7 OFF

8 - 15 PROGRAM 1

16 - 23 PROGRAM 2

24 - 31 PROGRAM 3

32 - 39 PROGRAM 4

40 - 47 PROGRAM 5

48 - 55 PROGRAM 6

56 - 63 PROGRAM 7

64 - 71 PROGRAM 8

72 - 79 PROGRAM 9

80 - 87 PROGRAM 10

88 - 95 PROGRAM 11

96 - 103 PROGRAM 12

104 - 111 PROGRAM 13

112 - 119 PROGRAM 14

120 - 127 PROGRAM 15

128 - 135 PROGRAM 16

136 - 143 SOUND MODE 1

144 - 151 SOUND MODE 2

152 - 159 SOUND MODE 3

160 - 167 SOUND MODE 4

Tri Disc 9 IR 7 Channel - DMX Values & Functions
