12

• Selecting the cooking zone

Touch ON/OFF(22) press the Selection bar

corresponding to the desired cooking zone.

• 9 Power levels

The hob features 9 power levels. Touch and scroll along the

Selection bar: to the right to increase the level of power; to

the left to decrease the level of power.

• Power booster

The product features a supplementary power level (after level

), which remains active for 5 minutes, after which the tempe-

rature returns to the previously set value.

Touch and scroll along the Selection bar (after level ) and

activate the Power Booster.

The Power Booster level is shown on the display of the selec-

ted zone with the symbol ” ”.

• Bridge Zones

Thanks to the Bridge function, the cooking zones are able to

work in a combined manner, creating a single zone with the

same power level. This function allows evenly distributed coo-

king with large-sized pots and pans.

The front “Master” cooking zone can be used in combination

with the corresponding “Secondary” cooking zone at the back.

To activate the Bridge Function:

- simultaneously select the two cooking zones you want to use

-

the Bridge indicator of the “Secondary” cooking zone lights up

“ ”

-

by means of the Selection bar of the “Master”

cooking zone it

will be possible to set the operating level (Power).

- to deactivate simply repeat same activation procedure.

• Temperature manager

Temperature Manager is a function that allows to set the most

suitable pre-set temperature to achieve the desired result (see

the power table at the end of this chapter).

Select the desired cooking zone.

Press once to choose the most suitable level:

Warming*

*See the Temperature Manager at the end of this chapter.

Press again to turn it o.

The following symbol appears on the display of the zone wor-

king in Temperature Manager mode “ ”

• Key Lock

The Key Lock allows to block the settings of the hob to pre-

vent accidental tampering, leaving the functions that have

already been set active.

Activation:

- press

- The LED over the button will turn on, to indicate that it has

been activated. Repeat the operation to deactivate.

• Timer

The Timer function is a countdown, which can be set for each

cooking zone, even simultaneously.

Note: the timer is a simple warning buzzer, which at the end of

the set minutes DOES NOT turn o the cooking zone.

Activation/Regulation of cooktop Timer function

- Select the cooking zone (power ¹ 0).

- Press to access the Timer function

- Regulate the duration of the Timer:

press the selector , to increase the automatic shut-down

time. Press the selector , to decrease the automatic shut-

down time. Repeat the operation for the other cooking zones.

Note: Each cooking zone can have a dierent Timer set; on

the display, the countdown of the last selected hob will be

shown for 10 seconds, after which the countdown with the

least remaining time will be shown.

When the timer has finished the countdown, there is an

acoustic signal (for 2 minutes, or it will stop when one of the

buttons on the hob is pressed), while the display will flash,

with the symbol “ “.

Note: on the side of the display of the cooking zone, the fo-

llowing symbol will appear .

To switch o the Timer:

- select the cooking zone

- set the value of the timer to “ “ , by means of

Note: the function remains active if no other key is pressed.

• Egg Timer

The Egg Timer function is a countdown independent of the coo-

king zones. The Egg Timer is activated by pressing .

Note: to regulate the Egg Timer function, follow the same pro-

cedure as for the Timer function.

When the timer has finished the countdown, there is an acoustic

signal (for 2 minutes, or it will stop when one of the buttons on the

hob is pressed), while the display will flash, with the symbol

“ “.

• Pause

The Pause function allows to suspend any function active on

the hob, bringing the cooking power to zero.

Activation:

- press

- a “ “ is displayed.

To deactivate the function:

Note:

this operation restores the settings to those prior to the pause.

- press

- within 10 seconds scroll to the right along the

Selection bar, relating to the cooking zone 2

Note: if the operation is not performed within this time the

pause function will remain active.

Note: if after 10 minutes, the Pause Function is not deactivated,

the cooktop will turn o automatically.

• Automatic Heat UP

The Automatic Heat UP function allows to reach the set power

faster; with this function it is possible to cook food faster, but

without the risk of burning it, because the temperature does

not exceed the set level.

This function is available for the levels of power 1-8.

Activation:

- With the cooking zone on, press , a

flashing will appear on

the display alternating with the power level set on the cooking zone.

Increasing the power level of the cooking zone : the automa-

tic heating function remains active, with the new temperature

setting; decreasing the power level of the cooking zone : the

automatic heating function is deactivated.

Note: If another cooking zone is selected at the same time, the

symbol

wi

ll light up again with a slightly brighter light and the

function can also be activated for this zone; however, the func-

tion remains active in the zone in which it has already been set.
