available for power levels from to .
Activation:
Select the key (2) of the zone to be used then slide your
finger in the selection bar (5) to activate the zone. Now
press the selection bar (5) in the zone of the desired
power for 3 seconds.
In the display (3) of that zone, the symbol appears
alternating with the set power.
By increasing the power level of the cooking zone, the
Automatic Heat Up function remains active, with the new
temperature setting;
Note: This function can be activated on several zones at
the same time.
Deactivate:
Select key (2) of the zone from which the Automatic heat
Up is to be removed and decrease the power level of the
cooking zone.
● Pause
The Pause function allows active functions on the hob to be
suspended, bringing the cooking power to zero.
Activation:
• press the key (10). The LED (10a) turns on.
Deactivate:
• press the key (10) for a few seconds.
With deactivation, the hob resumes working with the
settings set before the pause.
Note: if after 10 minutes, the Pause Function is not
deactivated, the hob will turn off automatically.
● Cooking Zone Timer
The Cooking Zone Timer function is a countdown that can
be set, even simultaneously, on each cooking zone. At the
end of the period set, the cooking zones switch off
automatically and the user is notified with a dedicated
acoustic signal.
Activation:
Note: this timer can only be started if the cooking zone is
active with power other than zero.
After having activated the desired cooking zone key (2),
press the key (8a)
the display (7a+7b) will activate and it will be possible to
program the timer.
To increase or decrease the time use the keys (8a) and
(8b).
The time is expressed in minutes and can be set to a
maximum of minutes. The last minute will be
displayed in seconds.
If desired, repeat the operation for several cooking
zones.
Each cooking zone can have a different Timer set; the
countdown of the cooking zone selected at that moment
will appear on the display (7a+7b).
Note: After activating the Bridge zone (only available for
some models) it is also possible to start the timer on this
zone.
Deactivate:
To switch off the Timer early, select the cooking zone by
pressing the key (2) then press the key (8a) until the timer
display reaches zero.
● Power Limitation
The Power Limitation function allows the product to be
used while limiting its maximum absorption, adjusting the
absorbed power in all active cooking zones, ensuring that
the total absorbed power of the hob does not exceed the
set maximum absorption level.
The default maximum power limit of the hob is 7200W. The
touch control may include a menu to configure the power
limit.
power limit. If the option is requested, the power limit can
be reduced by the user to 6000W, 3500W or 2800W.
Note: this operation must be performed within the first
30 seconds of connecting the induction hob to the
power supply, with the hob unlocked but not switched
on.
To enter the parameter management menu:
Disconnect the hob from the power supply, wait a few
seconds and reconnect the hob to the power supply.
UNLOCK the hob by holding down the key for a few
seconds.
Press the keys (8a)+(8b)+(10) at the same time for a few
seconds. The first number of the power value will be shown
on the display (3FL). The second number will be shown on
the display (3FR), e.g. 7200W: (3FR)=7 (3FL)=2.
To set a new parameter:
Press the keys (8a) or (8b) to move to other values. Once
the desired power is reached, save the setting by
simultaneously pressing the keys (8a)+(8b)+(10).
15
