Child Lock Function active

Pause function

Automatic Heat UP function

CHARACTERISTICS OF THE HOB

● Safe Activation

The product is activated only in the presence of pots on the

cooking zone: the heating process does not start or is

interrupted if there are no pots, or if these are removed.

● Pot Detector

The product automatically detects the presence of pots on

the cooking zones.

● Safety Shut Down

For safety reasons, each cooking zone has a maximum

operating time, which depends on the power level set.

● Residual Heat Indicator

When switching off one or more cooking zones, the

residual heat is indicated with a specific visual signal on the

display of the corresponding zone by the symbol .

HOB OPERATION

Note: Before activating any functions, the desired zone

must be enabled

● Power-on

Press (touch) ON/OFF(1) hob/extractor; the indicator

light will turn on to indicate that the hob/extractor fan is

ready for use.

Press again to turn off

Note: This function has priority over the others.

● Selecting the cooking zones

Touch (press) the Selection bar (3) corresponding to the

desired cooking zone.

● 9 Power Levels

The hob features 9 power levels. Slide your fingers along

the Selection bar (3):

to the right to increase the power level;

to the left to decrease the power level.

● Power Booster

The product features a supplementary power level (after

level ), which remains active for 5 minutes, after which

the temperature returns to the previously set value.

Touch and slide your fingers along the Selection bar (3)

(beyond level ) and activate the Power Booster

The Power Booster level is shown on the display of the

selected zone with the symbol .

● Bridge Zones

Thanks to the Bridge function, the cooking zones can

operate in a combined way, creating a single zone with the

same power level. This function allows evenly distributed

cooking with large-sized pots and pans.

It is possible to use the front “Master” cooking zone in

combination with the corresponding rear “Secondary” one

(to check which zones feature this function, see the

illustrated part of this manual).

To activate the Bridge Function:

• simultaneously press both selection areas of the

cooking zones you wish to use.

• the bridge indicator (21) of the selected cooking zones

will light up. The symbol appears on the display

• using the Selection area (3) of the “Master” cooking

zone, it will be possible to set the Operating Level

(Power).

Note: to disable the Bridge Function, simply repeat the

activation procedure.

● Temperature Manager

Temperature Manager is a function that allows you to keep

the heat at a constant temperature at an optimised power

level; this feature is ideal for keeping ready meals warm.

To activate the Function:

The Temperature Manager function can be enabled by

tapping the activation zone (4)

The following symbol appears on the display of the cooking

zone working in Temperature Manager mode .

● Key Lock

The Key Lock allows you to lock the settings of the hob to

prevent accidental tampering with the same, while leaving

the set functions enabled.

Activation:

• press (9)

• The LED above the button will turn on to indicate that it

has been activated

Repeat the operation to deactivate.

● Timer

The Timer function is a countdown that can be set, even

simultaneously, on each cooking zone.

At the end of the period set, the cooking zones switch off

automatically and the user is notified with a dedicated

acoustic signal.

To Activate/Adjust the hob Timer function:

With more than one cooking zone active, simultaneously

press and (8) several times until the icon (19)

appears in the cooking zone to be timed.

If only the zone to be timed is active, simultaneously press
