• Bases that are not flat or have rough surfaces.

• These lower the contact surface area between the

inductor and the cookware, reducing efficiency and

harming the cooking experience.

●Pre-existing cookware

You can check if the pot material is magnetic simply by

using a magnet. Pots are not suitable if they are not

magnetically detectable. The indications from the previous

paragraph also apply here.

● Recommended pot bottom diameters

IMPORTANT: if the pots are not of the correct size, the

cooking zones will not switch on. To see the minimum

pot diameters for each individual zone, consult the

illustrated section of this manual.

Please note: To preserve cooking performance and

product quality, the use of induction adapters is NOT

recommended.

● Energy saving

Use pots and pans with a bottom diameter equal to that of

the cooking zone; Use only pots and pans with flat bottoms;

- Where possible, keep the lid on pots during cooking;

Cook vegetables, potatoes, etc. with a minimal amount of

water to reduce the cooking time; Use the pressure cooker,

as it further reduces energy consumption and the cooking

time; Place the pot in the centre of the cooking zone drawn

on the hob.

USING THE EXTRACTOR FAN

The extraction system can be used in the duct-out version

with external evacuation, or in the recirculating version with

filtering and internal recirculation.

Consult the website www.elica.com and

www.shop.elica.com to view the full range of available

kits for the various installations in both the recirculating and

duct-out version.

● Duct-Out Version:

Vapours are exhausted outside via a series of pipes (to be

purchased separately). Connect the product to wall-

mounted exhaust pipes and holes with a diameter

equivalent to the air outlet (connecting flange). For more

information on the pipes and their dimensions see the page

relating to accessories in the installation manual - Duct-Out

version. The use of pipes and outlet holes in the wall with a

smaller diameter will reduce the extraction performance

and drastically increase the noise level. All responsibility in

this regard is therefore denied.

For maximum extraction efficiency: • We recommend a

maximum pipe route length of 7 linear metres. • We

recommend using no more than two 90° bends along the

entire 7 linear metres • Avoid drastic changes in the ducting

diameter, seeking to maintain a diameter of Ø 150 mm (or

a rectangular section of 222 x 89 mm).

● Recirculating Version:

The extracted air will be filtered in special grease filters and

odour filters before being sent back into the room. This

product includes filters and piping for an installation that

allows air to escape from the cabinet. For further

information on the accessories supplied, see the illustrated

part of this manual.

Important

It is possible to buy an extraction operation Kit. In this case

the charcoal filter must not be installed. Furthermore, the

use of the extraction kit may require a different installation

of the hood from what shown in this manual; therefore,

before starting the installation of the hood, buy the

extraction kit and consult the instructions enclosed with the

kit.
