19
4. USE OF PRODUCT
4.1 hOb CONTROLS
Ceramic Heater
• The ceramic heater is controlled by a 6
position knob.
• The ceramic heater is operated by
turning the control knob to the required
setting. Near each control knob is a
symbol which indicates the heater that is
controlled by that knob. The on/off light
on the control panel will show if any of
the ceramic heaters are in use.
3
OFF
LOHI
5
7
9
Knob Position Function
0
Off position
LO Keep warm position
3-5 Heating position at low heat
7-9 HI
Cooking, roasting and boiling
position
Important: The knob rotation
direction may differ according to the
product specification.
Residual Heat Indicator (if available)
• After using the hob there will be heat
stored in the vitroceramic glass called
residual heat. If the residual heat level is
greater than +140ºF, the residual heat
indicator will be active for the cooking zone
which is above this temperature.
• If the power supply to the hob is
disconnected while the residual heat
indicator is on, the warning light will flash
when the power is reconnected. The
display will flash until the residual heat has
decreased or until one of the cooking zones
is activated.
Hints and Tips
Important: When ceramic heaters are
operated in higher heat settings, the
heated areas may be seen switching
on and off. This is due to a safety device
which prevents the glass from overheating.
This is normal at high temperatures,
causing no damage to the hob and little
delay in cooking times.
WARNING:
• Never operate the hob without
pans on the cooking zone.
• Use only flat saucepans with a
sufficiently thick base.
• Make sure the bottom of the pan is dry
before placing it on the hob.
• While the cooking zone is in operation,
it is important to ensure that the pan is
centred correctly above the zone.
• In order to conserve energy, never use
a pan with a different diameter to the
hotplate being used.
Circular Saucepan
Base
Small Saucepan
Diameter
Saucepan Base
that has Not Settled
• Do not use pans with rough bottoms
since these can scratch the glass
ceramic surface.
• If possible, always place lids on the
pans.
• The temperature of accessible parts
may become high while the appliance is
operating. Keep children and animals
well away from the hob during operation
and until it has fully cooled after
operation.
• If you notice a crack on the cooktop,
it must be switched off immediately and
replaced by authorized service
personnel.
