Installation manual
9
3.2 Technical data
WH6–20LAC WH6–27LAC WH6–33LAC
Weight, net kg 354 425 560
Drum volume litres 180 240 300
Drum diameter
mm
725 795 795
Drum speed during wash
rpm
42 40 40
Drum speed during extraction
rpm
1055 1007 1007
G-factor, max. 450 450 450
Heating: Electricity kW 18 23 23
Heating: Steam
x x x
Heating: Hot water
x x x
Frequency of the dynamic force Hz 17.6 16.8 15.8
Floor load at max extraction kN 4.2 ± 1.0 5.2 ± 1.0 6.2 ± 1.3
Sound power/pressure level at extraction* dB(A) 84/68 83/68 82/66
Sound power/pressure level at wash* dB(A) 66/50 64/48 66/50
Heat emission of installed power, max %
5 5 5
* Sound power levels measured according to ISO 60704.
3.3 Connections
WH6–20LAC WH6–27LAC WH6–33LAC
Water valves DN
BSP
20
3/4”
20
3/4”
20
3/4”
Recommended water pressure kPa 200–600 200–600 200–600
Continuous operating pressure kPa 50–800 50–800 50–800
Capacity at 300 kPa l/min 30 60 60
Drain valve
⌀ outer
mm
75 75 75
Draining capacity l/min 170 170 170
Steam valve connection DN
BSP
15
1/2”
15
1/2”
15
1/2”
Recommended steam pressure kPa 300–600 300–600 300–600
Functioning limits for steam valve kPa 50–800 50–800 50–800
