WARNING!
Refer to “Safety information” chapter.
IMPORTANT
BEFORE INSTALLATION
Before the installation of the appliance, record the
information below from the rating plate. The rating plate is
on the bottom of the appliance casing.
Model
PNC
Serial number
Built-in appliances
Only use the built-in appliances after you assemble the
appliance into correct built-in units and work surfaces that
align to the standards.
Connection cable
• Use the correct mains cable of type H05BB-F Tmax
90°C (or higher) 3 x 4mm
2
with an all-pole 32A breaker.
• The earth cord (green/yellow cable) must be 2cm longer
than phase and neutral cable (blue and brown cables).
*Note: The clearance must meet or exceed the minimum recommended for both the rangehood
and cooktop.
Refer to the rangehood installation manual.
min.
60mm
=
=
=
=
=
=
=
=
=
=
R 5mm
R 5mm
520mm 520mm
490
+1
mm
490
+1
mm
560
+1
mm
560
+1
mm
min.
500mm*
min.
50mm
EHI635BE & EHI635BF EHI645BE & EHI645BF
R 5mm
520mm
EHI745BE
490
+1
mm
680
+1
mm
R 5mm
520mm
EHI955BE
490
+1
mm
880
+1
mm
R 5mm
520mm
EHI977BE
490
+1
mm
880
+1
mm
min.
16mm
min. 20mm
min.
25 mm
29 electrolux.com.au
INSTALLATION
min. 20mm
