Installation manual
29
Alternative measuring method
Adjusting the air flow may only be carried out by authorized personnel.
Use a home made U tube manometer, a hose (max. outer ⌀ 10 mm and min. outer ⌀ 5 mm), with water. Insert one
end of the hose in the hole (A) (after the plug has been removed), hold the hose according to the picture so that the
water is in level.
Start the machine and measure the difference between the water in one of the hose ends with the other.
1 mm = 10 Pa.
X mm
A
fig.7528B
Note!
When the air flow is adjusted remount the plug in the hole (A) and lock the damper in the new position.
Remount the rear panel.
