WARNING!
The gas connection pipe must not touch
the part of the appliance shown in the
illustration.
3.10 Flexible nonmetal pipes
connection
If you have an easy access to the connection,
you can use a flexible pipe. The flexible pipe
must be tightly attached by clamps.
In installation always use the pipe holder and
the gasket. The flexible pipe can be applied
when:
• it can not get hotter than room
temperature, higher than 30 °C,
• it is not longer than 1500 mm,
• it has no narrowing anywhere,
• it is not twisted or tighten,
• it does not get in touch with sharp edges
or corners,
• it's conditions can be easily checked.
When checking the flexible pipe make sure:
• it does not show cracks, cuts, marks of
burnings on the two ends and on its full
length,
• the material is not hardened, but shows its
correct elasticity,
• the fastening clamps are not rusted,
• expired term is not due.
If one or more defects are visible, do not
repair the pipe, but replace it.
The gas supply ramp is on the rear side of
the control panel.
3.11 Adjustment to different types
of gas
Let only an authorized person do the
adjustment to different types of gas.
If the appliance is set for natural gas you
can change it to liquid gas, with the
correct injectors.
The gas rate is adjusted to suit.
WARNING!
Before you replace the injectors, make
sure that the gas knobs are in the Off
position. Disconnect the appliance from
the electrical supply. Let the appliance
cool down. There is a risk of injury.
The appliance is set to default gas. To
change the setting always use the gasket
sealing.
A B C
A. End of shaft with nut
B. Gasket
C. Elbow (if needed)
3.12 Hob injectors replacement
Replace the injectors when you change the
gas type.
1. Remove the pan supports.
2. Remove the caps and crowns of the
burner.
3. Remove the injectors with a socket
spanner 7.
4. Replace injectors with the ones
necessary for the type of gas you use.
ENGLISH 39
