- C -

111167/3

Riferimento per schema elettrico-pneumatico / Reference for electrical-pneumatic diagram / Référence pour schéma électrique-pneumatique

Verweis auf den elektrischen-pneumatisches Schaltplan / Referencia por esquema eléctrico-neumatico [24VDC]

Codice

Code

Kode

Codigo

Sigla

Abb.

Sigle

Abkurz.

Sigla

Denominazione Description Description Bezeichnung Descripción

02119

FA-FB

Fusibile 6,3A ø 5x20 Fuse 5x20 6,3A Fusible 5x20 6,3A Sicherung 5x20 6,3A Fusible 6,3A 5x20

08927 Portafusibile Fuse holder Tableau des fusibles Sicherungshalterung Porta fusible

02851/1

Pressostato 1/4" XP110 (4,5BAR)

Pressure switch XP110 1/4"

(4,5BAR)

Pressostat 1/4" XP110 (4,5BAR) Druckwaechter XP110 1/4" (4,5BAR) Presostato XP110 1/4" (4,5BAR)

07890

Connettore cablato L=1m Wired connector L=1m Connecteur filaire L=1m Kabelstecker L=1m conector con cable L=1m

08059/IBA 6A Contattore 9A 24VDC 50/60 Hz Contactor 9A 24VDC 50/60 Hz Contacteur 9A 24VDC 50/60 Hz Schtuzschalter 9A 24VDC 50/60 Hz Contactor 9A 24VDC 50/60 Hz

08060/IBA 6V Contattore 12A 24VDC 50/60 Hz Contactor 12A 24VDC 50/60 Hz Contacteur 12A 24VDC 50/60 Hz Schtuzschalter 12A 24VDC 50/60 Hz Contactor 12A 24VDC 50/60 Hz

08064 51V

Relè termico 2,5-4A Thermal cutout 2,5-4A Rerais thermique 2,5-4A Thermisches relais 2,5-4A Rele termico 2,5-4A

08065 51A Relè termico 1-1,6A Thermal cutout 1-1,6A Rerais thermique 1-1,6A Thermisches relais 1-1,6A Rele termico 1-1,6A

08074/IBA

6sic

Contattore 20A 4P 24VCC Contactor 20A 4P 24VCC Contacteur 20A 4P 24VCC Schtuzschalter 20A 4P 24VCC Contactor 20A 4P 24VCC

08124

Contatto ausiliario Contact Contact auxiliaire Kontact Contacto auxiliar

08222

69-70-77

Regolatore Regulator Regulateur Regler Regulador

08224

Manometro 0-10BAR Manometer 0-10BAR Manometre 0-10BAR Manometer 0-10BAR Manometro 0-10BAR

08319 Cavo Cable Câble Kabel Cable

08371

Silenziatore Silencer Silencieux Schalldämpfer Silenciador

08530

Connettore cablato DB25 L=3m

(PLC)

Wired connector DB25 L=3m (PLC) Connecteur filaire DB25 L=3m (PLC) Kabelstecker DB25 L=3m (PLC)

conector con cable DB25 L=3m

(PLC)

08877

Filtro riduttore ½" AW40-F040D-2

Pressure regulator filter ½" AW40-

F040D-2

Filtre moderateur de pression ½"

AW40-F040D-2

Druckreglerfilter ½" AW40-F040D-2

Filtro regulador de presion ½"

AW40-F040D-2

08224

Manometro 0-10BAR Manometer 0-10BAR Manometre 0-10BAR Manometer 0-10BAR Manometro 0-10BAR

08324 Elemento filtrante Filter element Filtre element Filterelement Cartucho filtrante

68707 09/03-AP/PP, 12/13-TB

Elettrovalvola 2x3/2 Solenoid valve 2x3/2 Electrovanne 2x3/2 Magnetventil 2x3/2 Electrovalvula 2x3/2

68709

00-PRF, 01-SP, 02-FC, 04-RM

05-PR, 06-PMC

#(13)

,07-PD,

7B-PSC

#(13)

, 08-PS

08B-PDC

#(13)

, 19-PRP

Elettrovalvola 5/2 mono Solenoid valve 5/2 mono Electrovanne 5/2 mono Magnetventil 5/2 mono Electrovalvula 5/2 mono

68710 10/11-RT, 14/15-SC

Elelettrovalvola 5/3 CC Solenoid valve 5/3 CC Electrovanne 5/3 CC Magnetventil 5/3 CC Electrovalvula 5/3 CC

68710/K

Guarnizioni SY30M-9-1A (10) Rubber seals SY30M-9-1A (10) Joints en caoutchouc (10)

Kit dichtungen SY30M-9-1A (10)

Sellos de goma (10)

12620

VSN-VSM

Valvola scarico rapido 3/8 AD6050 Quick discharge valve 3/8 AD6050 Vanne decharge rapide 3/8 AD6050 Schnellablassventil 3/8 AD6050

Valvula descarga rapida 3/8

AD6050

10460

Silenziatore Silencer Silencieux Schalldämpfer Silenciador

102534 60-71-72

Miniregolatore Ø4 M5 Regulator Ø4 M5 Regulateur Ø4 M5 Regler Ø4 M5 Regulador Ø4 M5

104434 AL Alimentatore MDR60-24: 2,5 Power pack MDR60-24: 2,5 Alimentateur MDR60-24: 2,5 Speiser MDR60-24: 2,5 Alimentador MDR60-24: 2,5

105013

Regolatore IR1020-F01 Regulator IR1020-F01 Regulateur IR1020-F01 Regler IR1020-F01 Regulador IR1020-F01

02197

Manometro 0-4BAR Manometer 0-4BAR Manometre 0-4BAR Mmanometer 0-4BAR Manometro 0-4BAR

105015 16/17-TM

Elettrovalvola 5/3 Solenoid valve 5/3 Electrovanne 5/3 Magnetventil 5/3 Electrovalvula 5/3

102320 PLC

PLC Fatek FSB 36IN-24OUT PLC FSB 36IN-24OUT PLC Fatek FSB 36IN-24OUT PLC Fatek FSB 36IN-24OUT PLC Fatek FSB 36IN-24OUT

106810

Microfiltro disoleatore Mist separator Filtre micronique Mikrofilter Oelabscheider Filtro micrónico

09144 Elemento filtrante Filter element Filtre element Filterelement Cartucho filtrante

104691

Interruttore di sicurezza Safety switch Interrupteur de sécurité Sicherheitsschalter interruptor de seguridad

104692

Azionatore snodato Actuator articulated Actionneur articu Actuator Gelenk Actuador articulado

107405

69-70 Miniregolatore compatto Ø4 Regulator Ø4 Regulateur Ø4 Regler Ø4 Regulador Ø4

108251

Morsetto Terminal Borne Klemme Terminal 6mmq

109629

#(2)

Connettore RJ45-8P8C Connector RJ45-8P8C Connecteur RJ45-8P8C Kabel RJ45-8P8C Cable RJ45-8P8C

109630

#(2)

Cavo ETH CAT5e SH PM 300m/m

Cable ETH CAT5e SH PM 300m/m Câble ETH CAT5e SH PM 300m/m Kabel ETH CAT5e SH PM 300m/m Cable ETH CAT5e SH PM 300m/m

110945

#(2)

Presa ETH RJ45 Socket ETH RJ45 Prise ETH RJ45 Sockel ETH RJ45 Toma ETH RJ45

# Optional
